1. Keihin Parts for 1966-73 P50, PC50, PC50A, PC50K1, PF50, PS50

April 3, 2021

== carb ID# ============  M O P E D S  ===========
1. 50A, 50B– 1966-68 Honda P50 xxxxxxxxxxxx  40 kmh OHC
1. 610 (50B) 1967-68 Honda P50 Little Honda     40 kmh OHC
2. C4B, C5B   1969-70 Honda PC50A xxxxxxx  40,50 kmh OHC
2. C5A, C5A   1969-70 Honda PC50 Little Honda   40 kmh OHC
2. S4A, S5A   1969-70 Honda PS50  xxxxooo x 40,50 kmh OHC
2. F4A, F5A   1970-73 Honda PC50K1, PF50 x  40,50 kmh OHV
2. S4B, S5B   1970-71 Honda PS50  xxxxxxxxooo  50 kmh OHV









1. Keihin
carb model code years  frame number range      models
50A-000 #044 1966-67 P25-A000001-00000 Honda P25
50A-610 #044 1967-68 P50-100001-148606 Honda P50
50A-610 #044 1967-68 P50-100001-148606 Honda P50 Little Honda (US)
50B-NL   #044 1967-68 P50-128651-148606 Honda P50 (Netherlands)
50B-000 #044 1968-68 P50-148607-000000 Honda P50
50B-000 #044 1968-68 P50-148607-000000 Honda P50 Little Honda (US)

1964 P25 (NL model)

1967 Honda P50

1968 P50 (US model)















Bore:  42.0 mm, stroke 35.6 mm, displacement: 49.3 cc. P50’s have down-draft carburetors, unusual.
50B carbs do not have a replaceable float valve. It’s part of, and only sold with, the float chamber cover.
50B has a larger carb size ∅11? and  jet #68 or 62. 50A has a smaller carb size ∅9? and jet #60 or 55.

#0  16010-044-004

#1  16010-044-680

















Honda P50 carburetors

  =00 quantity   Keihin
0#=00 ⇓⇓⇓⇓   (a)50A(b)50A-610  (c)50B-N  (d)50B
0#=00 abcd  price   Honda part#   description        specs
00=00 1000  N/A 16100-044-030
00=00 1000  N/A 16100-044-315 carburetor 50A-000 ’66-67
00=00 0100  N/A 16100-044-405 carburetor 50A-610 ’67-68
00=00 1100  N/A 16010-044-004 gasket set 10-piece 4 12 13
00=00 1100  N/A 16010-044-004 15 20 20 20 24 27 32
00=00 1100  N/A 16151-044-681 jet needle
11=00 1100  N/A 16125-044-004 float valve set
12=00 1100  N/A 16173-001-004 rubber seal ring
13=00 1100  N/A 16188-044-004 valve fiber washer 7.2 x 10.5
16=00 1000  N/A 16133-044-004 needle jet
16=00 0100  N/A 16133-044-681 needle jet 2.6 x 1.55
17=00 1000  N/A 0-99144-03804 slow jet 38
17=00 0100  N/A 0-99144-03504 slow jet 35
24=00 1100  N/A 16123-044-004 jet access gasket
25=00 1000  N/A 0-99120-06014 main jet 60
25=00 0100  N/A 0-99120-05514 main jet 55
26=00 1100  N/A 16112-044-004 float chamber cover
30=00 4400 0$1 0-93600-04008 sunk-phillips screw M4 x 8
32=00 1100  N/A (not sold separately) choke shaft o-ring
=======================================
00=00 0010  N/A 16100-044-681 carburetor 50B-NL ’67-68
00=00 0001  N/A 16100-044-683 carburetor 50B-00 1968
01=00 0011  N/A 16010-044-680 gasket set 4-piece 4 15 20 27
1n=27 1111 none16174-044-004 float o-ring 1.5 x 40 (43od)
1p=04 1111 0$5 16171-044-004 top rubber washer 10 x 15 x 1
1r=15 1111 0$5 16175-001-004 needle jet o-ring  2 x 4 (8od)
1i =20 3333 0$2 16175-260-004 jet/screw o-ring 2 x 2.5 (6.5od)
02=00 0011  N/A 16012-044-681 needle set 2a 2b 2c 2d
2a=06 1111 0$5 16156-044-004 throttle w-clip
2b=07 1111 0$2 16157-044-004 needle e-clip 1.5 for 2.0 needle
2c=00 0011  N/A 16151-044-683 jet needle
2d=00 0011  N/A 16133-044-683 needle jet 2.6 x 2.0
03=00 1111  N/A 16014-044-004 top set 3a 3b 1p
3a=03 1111  N/A 16119-044-004 carb top M16-1.0
3b=02 1111 0$3 16118-044-004 cable adjuster male M6-0.75
04=00 0011  N/A 16015-044-014 chamber/valve set 4a 1n
4a=00 0011  N/A 16112-044-014 chamber cover w/valve
05=00 1111  N/A 16016-044-014 screw set 5a 5b 5c 5d 1i 1i
5a=18 1111  N/A 16163-044-014 idle speed screw
5b=19 1111  N/A 16162-259-004 idle air screw
5c=21 1111  N/A 16182-011-004 idle speed spring
5d=22 1111  N/A 16181-202-004 idle air spring
06=00 0011  N/A 16022-044-680 valve (slide) set 6a 6b
6a=09 1111  N/A 16141-044-683 throttle valve (slide)
6b=05 1111  N/A 16185-044-004 throttle spring
10=00 0022  .80 00-93500-03008 phillips screw M3 x 8
13=00 0o10  N/A 99114-044-0681 main jet 68
13=00 00o1  N/A 00-99120-06214 main jet 62
14=00 0011  N/A 99203-044-5201 slow jet

Part Sets: Before 1968 most Honda parts were sold individually. That is how the top carb is listed and illustrated. Starting in 1968, many Honda parts were only sold in sets. That is how the bottom carb is listed and illustrated.

Parts for the top carb that are the same as the bottom, are only listed in the bottom carb parts.



2. Keihin
size carb model code eng  years    frame number range      Honda models
0∅9  C4A on #063 ohc 1969-70 PC50-1000000 to 1057917   PC50 xxxxxx40 km/h
∅10  C5A on #063 ohc 1969-70 PC50-1057918 to 1060412   PC50 (1306302) 50 km
∅10  C5A on #063 ohc 1969-70 PC50-1060413 to 0000000   PC50 Little Honda (US)
∅10  C5A on #064 ohc 1969-70 PS50-1000000 to 1001412   PS50 xxxxxx50 km/h
∅10  S5A on #064 ohc 1969-70 PS50-1001413  to 0000000   PS50 xxxxxx50 km/h
0∅9  C4B on #081 ohv 1970-71 PC50-2000000 to 2039616   PC50K1 xxxx40 km/h
∅10  C5B on #081 ohv 1970-71 PC50-2039617 to 0000000   PC50K1 xxxx50 km/h
∅10  S5B on #082 ohv 1970-71 PS50-2000000  to 0000000   PS50K1 xxxx50 km/h
0∅9  F4A on #081 ohv 1971-73 PC50-0000000 to 0000000   PC50K1 xxxx40 km/h
∅9 o F4A on #099 ohv 1970-73 PF50-1000000 to 0000000   PF50 Amigo  40 km/h
∅10  F5A on #081 ohv 1971-73 PC50-0000000 to 0000000   PC50K1 xxxx50 km/h
∅10  F5A on #099 ohv 1970-73 PF50-1000000 to 0000000   PF50 Amigo  50 km/h

1968 PC50A (Euro)
with OHC engine

1969-70 PC50 (USA) with OHC engine

1973 Honda PC50K1
with OHV engine

















1969-70 PC50: Before April 1970, the PC50 had a OHC engine (over head cam). Bore 42.0 mm, stroke 35.6 mm, displacement 49.3 cc. The valves were operated by a cam in the head, driven by a cam chain.

Spigot mount: The Keihin C4A, C5A, C4B, C5B carburetors for the early 1969-70 PC50A were spigot mount type. They had a round float bowl gasket (with three flat sides when installed), a push-in jet, jet pad, completely round “donut” float, all metal float needle with replaceable float seat.

1970-73 PC50K1: After April 1970, the PC50K1 had a OHV engine (over head valve). The valves were operated by pushrods from a cam down in the case.

Flange mount: The Keihin F4A, F5A, carburetors for the 1970-73 PC50K1 were flange mount type with 32mm bolt spacing. There was a diamond shaped gasket rather than an o-ring like all later flange mount carbs. Everything else was the same, round float bowl gasket (with three flat sides when installed), a push-in jet, jet pad, completely round “donut” float, all metal float needle with replaceable float seat.

Keihin C5A carburetor

Keihin F4A carburetor

















#1 16010-063-000
1d 1e 1n 1p     1r

#1 16010-063-004
1d 1e 1n 1p 1q   .

#1 16010-114-305
1d 1e 1n 1p     1r 1v















1969 Honda PC50 carburetor illustration

Keihin C4A, C4B, C5A, C5B

0o quantity
o# ⇓⇓⇓⇓⇓⇓  Keihin (a)C4A (b)C5A (c)C4B (d)C5B (e)F4A (f)F5A
o# abcdef  price   Honda part#    description       specs
00 100000  N/A 16100-063-690 carb. C4A   ∅9  69-70 PC50
00 010000  N/A 16100-063-004 carb. C5A ∅10  69-70 PC50, PS50
00 001000  N/A 16100-081-690 carb. C4B   ∅9  70 PC50K1 < 2039617
00 000100  N/A 16100-081-014 carb. C5B ∅10  70 PC50K1 > 2039616
00 000010  N/A 16100-099-690 carb. F4A   ∅9  70-73 PC50K1, PF50
00 000001  N/A 16100-099-600 carb. F5A ∅10  70-73 PC50K1, PF50
01 111011 $25 16010-063-004 gasket solo-set   1d 1e 1n 1p 1q
01 000100 $17 16010-063-000 gasket solo-set   1d 1e 1n 1p oo 1r
01 000100 $20 16010-114-305 gasket multi-set 1d 1e 1n 1p 1q 1r
1d 111111 0$2 16176-551-004 main jet o-ring 1 x 3 (5 od)
1e 111111 $13 16197-063-004 jet pad disk Ø7.3 x 1.9
1n 111111 none  16173-063-004 float bowl o-ring 1.5 x 40 (43 od)
1p 111111 0$5 16171-044-004 top rubber washer 10 x 15 x 1
1q 111011 0$9 16189-056-004 drain screw seal washer 6 x 8 x 0.5
1r  000100 0$5 16175-001-004 drain screw o-ring C5B 2 x 4 (8od)
02 001101  N/A 16012-064-004 needle set F5A 2a 2c 2d 2f
2a 111101  N/A 16051-063-004 jet needle C4A C5A C4B C5B F5A
2b 000010  N/A 16051-063-690 jet needle F4A
2c 111111 0$5 16156-044-004 needle w-clip
2d 111111 0$2 16157-044-004 needle e-clip 1.5 for 2.0 needle
2e 110000  N/A 16133-063-004 needle jet C4A C5A 2.1 x 2.5
2f  001101  N/A 16133-081-004 needle jet C4B C5B F5A
2g 000010  N/A 16133-081-690 needle jet F4A
03 111111  N/A 16013-064-004 float set 3a 3b 3c 3d 3e 10
3a 111111  $13 16123-063-004 float needle (all metal)
3b 111111  N/A 16122-063-004 float
3c 111111  N/A 16127-063-014 float arm
3d 111111  N/A 16126-063-014 float hinge pin
3e 111111  N/A 16196-063-014 float pin plate
04 111111  N/A 16014-064-004 top set 4a 4b 1p
4a 111111  N/A 16119-063-004 top with pipe
4b 111111  N/A 16118-045-004 cable adjuster female M6-0.75
05 111011  N/A 16015-064-004 chamber set 5a 5c 1n 1q
05 000100  N/A 00000-000-000 chamber set 5b 5d 1n 1r
5a 111011  N/A (not sold separately) chamber bare
5b 000100  N/A (not sold separately) chamber bare
5c 111011  N/A 16164-225-004 drain screw C4A C5A C4B F4A F5A
5d 000100  N/A 16162-304-004 drain screw C5B
06 111111  N/A 16016-063-004 adjustment screw set
6a 111111  N/A 16163-063-014 idle speed screw
6b 111111  N/A 16162-044-004 idle air screw & spring
6c 111111  N/A 16181-250-004 idle speed spring
07 111111  N/A 16022-063-004 throttle valve set
7a 111111  N/A 16141-063-004 throttle valve (slide)
7b 111111  N/A 16185-044-004 throttle spring
09 111111  N/A 16194-063-004 cable pipe cover
10 222222 $1.00 93500-0300500A phillips screw M3 x 5
11 222222 $1.00 93500-040120A phillips screw M4 x 12
12 111111 $0.50 94111-030000 spring washer M3
13 222222 $0.20 94111-04000 spring washer M4
15 101010  N/A 99201-063-0550 main jet #55 push-in see jets below
15 010101  N/A 99201-063-0620 main jet #62 push-in see jets below
18 111111  N/A (not sold separately) idle jet press-in tube 0.35=0.0138″



Keyster 0605 kit for PC50A has no #1e
for C4A except no 1e, C5A  except   15 1e
for C4B except 2f 1e, C5B except 2f 15 1e
for F4A except 2g 1e, F5A except 2f 15 1e

#5c #5d drain plugs























Zenith 11-HL on 1970’s Spanish Honda PS50

1970 Honda PS50













3. Keihin Parts for 1977-83 NC50, NA50, NX50, NU50, NCZ50

April 3, 2021

== carb ID# ============  M O P E D S  ===========
6. PA 08B-A  1977-78 Honda NC50 Express xxx    30 mph TS
6. PA 08B-B  1977-79 Honda NC50, NA50  xxxx    30 mph TS
6. PA 08C-A  1978-79 Honda NC50, NA50  xxxx    30 mph TS
6. PA 08E-A  1980-80 Honda NC50 Express xxx    30 mph TS
6. PA 08E-B  1980-80 Honda NC50 Express xxx    30 mph TS
6. PA 08D-A  1980-80 Honda NA50 Express II x   30 mph TS
7. PA 12A-A  1981-81 Honda NCZ50 Moto Compo
7. PA 15A-A  1981-81 Honda NC50 Express xxx    30 mph TS
7. PA 16A-A  1981-81 Honda NA50 Express II  x   30 mph TS
7. PA 13B-A  1981-82 Honda NX50 Express SR x   30 mph TS
7. PA 13B-B  1982-83 Honda NC50 Express xxx     30 mph TS
7. PA 13E-A  1982-83 Honda NU50 Urban Express 30 mph TS
7. PA 25A-A  1982-83 Honda NC50AA, NU50AA      25 mph TS











6. Keihin
size     carb  model code  year 00 frame number range  000  model
∅12 PA08B-A or B #147 1977 NC50-1139281 to 0000000 NC50 Express (US)    30 mph
∅12 PA08B-A or B #147 1978 NC50-2000013 to 0000000 NC50 Express (US)    30 mph
∅12 PA08E-A or B #147 1979 NC50-2100011 to 0000000 NC50 Express (US)    30 mph
∅12 PA08E-A or B #147 1980 NC50-2200005 to 0000000 NC50 Express (US)    30 mph
∅12 PA08B-B    on #163 1979 AB01-5000001 to 0000000 NA50 Express II (US) 30 mph
∅12 PA08D-A    on #163 1980 AB01-5200001 to 0000000 NA50 Express II (US) 30 mph



1977 Honda NC50 Express

1978 Honda NC50 Express

’79 NC50 Express



















1980 Honda NC50 Express

1980 Honda NA50 Express II























#0  16100-147-675
Keihin PA08B-A

#0 16100-147-676
Keihin PA08B-B

#0 16100-147-711
Keihin PA08E-A



















#0 16100-147-712
Keihin PA08E-B

16100-163-771
Keihin PA08D-A

















Flange Mount: 38 mm hole spacing. 2 x 20 (24 od) intake o-ring.

Honda Express carburetor versions, showing things that are different.

Honda Express carburetor versions

Cable choke: This carburetor has a throttle cable and a choke cable coming straight up and looping around. It has no vent hoses, vacuum hoses, or oil lines going into it. The oil injection goes into the intake manifold. The float reservoir vent is just a small tube slanting downward.

As with most Honda carburetors, fuel is never allowed to spill onto the engine or anything else. Instead an overflow tube inside the float chamber allows any overflow fuel to flow out and down the drain hose and onto the ground below the engine.

The 1977-79 Honda NC50 and NA50 each had two carburetor versions, PA08B-A and PA08B-B. Regardless of the year, or the VIN number, they could have either version. So the customer had to look at the model number stamped into the carburetor, and tell the Honda dealer that number, to get certain parts correct.

Oil injection hose location: The 1977-79 Honda Express had the oil hose going into the intake manifold, not the carburetor. The 1980 and later models had the oil injection hose going into the carburetor at the throttle slide area. There must have been some benefit, like maybe throttle slide lubrication.

16010-143-620
has a, c, d, e, f, g
for PA08 BA

16010-143-305
a, c, d, e, f, g, h, i
for PA08 BA

16010-147-004
has b, c, f, g
for PA08 BB, EB

16010-147-711
has b, c, d, f, g
08 BB EB DA EA

16010-147-505
has b, c, d, f, g, i
08 BB EB DA EA



















    quantity
o# ⇓⇓⇓⇓⇓  Keihin PA(a)08BA (b)08BB (c)08EA (d)08EB (e)08DA
o# abcde price  Honda part#x  description xxx specs
10 1oooo  N/A 16100-147-673
10 1oooo  N/A 16100-147-675 carburetor 77-79 NC50 PA 08B-A
10 o1ooo  N/A 16100-147-676 carb 77-79 NC50 NA50 PA 08B-B
10 oo1o0  N/A 16100-147-711 carburetor  1980 NC50 PA 08E-A
10 oo01o  N/A 16100-147-712 carburetor  1980 NC50 PA 08E-B
10 oooo1  N/A 16100-163-771 carburetor  1980 NA50 PA 08D-A
o1 10ooo $26 16010-143-620 gasket solo-set   1a o c d e f g
o1 10ooo $28 16010-143-305 gasket multi-set  1a o c d e f g h i
o1 01o1o $23 16010-147-004 gasket solo-set   oo b c o o f g
o1 o1111 $23 16010-147-711 gasket solo-set   oo b c d o f g
o1 o1111 $24 16010-147-505 gasket multi-set oo b c d o f g o i
1a 100o0 $$3 00000-000-000 top rubber washer 10 x 18 x 1
1b o1111 $$8 00000-000-000 top rubber washer 13 x 16.5 x 1
1c 11111 $$2 00000-000-000 intake o-ring 2 x 20 (24 od)
1d 1o1o1 0$2 16176-551-004 jet or screw o-ring 1 x 3 (5 od)
1e 1o0oo $13 16197-063-004 jet support pad disk Ø7.5 x 1.8
1f  11111 $18 00000-000-000 float bowl gasket  Ø1.5 NC50-type
1g 11111 $$2 00000-000-000 drain plug o-ring 1.5 x 4 (7 od)
o2 1oo1o $21 16011-881-741 float needle valve  stirrup
o2 1oo1o $36 16011-881-741 float needle genuine stirrup
o2 o11o1 $22 16155-883-005 float needle valve regular
o3 1o1o0  N/A 16012-147-004 needle set 3a 3b 3c 3d 08BA EA
o3 ooooo $22 16012-130-640 needle set 3a 3b 3c 3d PA 03A-A
o3 ooooo $22 16012-165-014 needle set 3a 3b 3c 3d PA 03B-A
o3 o1o11 $15 16012-147-014 needle set 3a 3b 3c 08BB EB DA
3a 11111 0$5 16156-044-004 jet needle w-clip
3b 11111 0$2 16157-044-004 jet needle e-clip 1.5 for Ø2.0 needle
3c 11111 $10 00000-000-000 jet needle Ø2.0 D348 thick 08B-A,
3c 11111 $10 00000-000-000 PA 08B-B, 03A-A, 00A, 01A
3c ooooo $10 00000-000-000 jet needle Ø2.0 D117 thin 03B-A,
3c ooooo $10 00000-000-000 PA 03C-A, 03D-A, 03H-B, 03M-A, etc
3d 1o1oo  N/A 00000-000-000 needle jet (emulsion tube) 08BA 08EA
3d o1o11  N/A 00000-000-000 needle jet & jet fixed 08BB 08EB 08DA
3d ooooo $10 00000-000-000 needle jet (emulsion tube) PA 03A-A
3d ooooo $10 00000-000-000 needle jet (emulsion tube) PA 03B-A
o4 1oo1o  N/A 16013-143-620
o4 1oo1o  $46 16013-099-691 float set 4a oo 4c 4d black stirrup
o4 o11o1 $28 16013-147-004 float set oo 4b 4c 4d white regular
4a 1oo1o  N/A 00000-000-000 float bare, solid black foam stirrup
4b o11o1 $21 00000-000-000 float bare hollow white plastic regular
4c 11111 $$4 00000-000-000 hinge pin substitute Ø2 x 18.5
4d 11111 $$3 0-93600-04006 hinge screw M4x6 sunk phillips

1977-79 NC50 idle adjustment screws
7a idle speed screw, tighter is faster
7c idle air mix screw, tighter is richer

o5 1oooo $23 16014-143-620 top set substitute 5a 1a M20-1.0
o5 o1111 $22 16014-147-004 top set substitute 5a 1b M18-1.0
o6 1oooo  N/A 16015-147-004 chamber set A 6a oo 6c 1e 1f 1g for jet pad
o6 o1111  N/A 16015-147-014 chamber set B oo 6b 6c oo 1f 1g for no pad
6a 1oo0o  N/A 16015-147-004 float bowl A shallow with pad holder
6b o1111  N/A 16015-147-014 float bowl B shallow, no jet pad holder
6c 11111 $16 00000-000-000 float drain screw M6x20 special
o7 11o1o $15 16016-143-620 screw set 7a b c d idle air
o7 oo101  N/A 16016-147-711 screw set 7a b o d e f g idle fuel
7a 11111 $$4 00000-000-000 idle speed screw M4x19 special
7b 11111 $$2 00000-000-000 idle speed screw spring Ø5.6 x 10
7c 11o1o  N/A 00000-000-000 idle air screw M6-0.75 thick tip
7d 11111 $$7 00000-000-000 idle air or fuel spring Ø4.8 x 9
7e oo1o1  N/A 00000-000-000 idle fuel screw M6-0.75 thin tip
7f  oo1o1 $$3 00000-000-000 idle fuel screw washer 3.1 x 5.0 x 0.5
7g oo1o1 0$2 16176-551-004 idle fuel screw o-ring 1 x 3 (5 od)

1980-83 NC50 idle adjustment screws
7a idle speed screw, tighter is faster
7e idle fuel mix screw, tighter is leaner

o8 11111 $38 16022-143-620 valve set 8a, 8b
8a 11111 $22 00000-000-000 throttle slide Ø13 #15A
8b 11111 $12 00000-000-000 throttle spring original Ø9.5 x 42
8b 11111 $$7 00000-000-000 throttle spring substitute shorter, stiffer
o9 11111 $25 16046-147-004 choke set substitute 9a 9b 9c
9a 11111 $15 00000-000-000 choke top substitute M12-1.0
9b 11111 $$4 00000-000-000 choke spring substitute
9c 11111 $12 00000-000-000 choke slide substitute

11 11111 $2.00 16118-166-004 rubber boot substitute Dellorto
12 22222 $1.00   93500-04012 bowl screw M4x12 pan phillips
13 22222 $0.20   94111-04000 lock washer M4 split
14 11111 $1.00 95001 – 35003 hose substitute 1/8 x ¼ 3.1 x 6.3


15 11111  N/A 95002 – 02070 drain hose clamp B7 (for 7 not 6.3)
16 10o0o  N/A 99201.081.0780 push-in jet 78 08BA
16 10o0o $23 substitute jet, #70 drilled to 78 08BA
16 01111  N/A fixed needle jet & jet pressed in 08BB EA EB DA
this jet is 0.78mm 0.0307″, cleaned with a #69 drill 0.0292″

00 22222 $1.00 mount bolt, nut and washer M6 x 20



Float: The white float with non-stirrip needle for PA08B-B and the black float with stirrup type needle for PA08B-A do not interchange. The white float is too “tight” on the PA08B-A. Something restricts its movement. The black float is too “loose” on the PA08B-B. It moves a lot before moving the needle.

Main Jet: On PA08BB, EA, EB and DA versions the main jet is a tamper-proof tight press-fit type, in the center. The jet cannot be removed, and cannot be replaced. It is 0.78 mm – 0.0307″, and can be cleaned perfectly with a #69 drill 0.0292″.

On a PA08BA the main jet presses or slides in and out, and is supported by a rubber disk. If the disk is missing, the jet can slide downward, allowing fuel to get past the jet o-ring, causing a rich fuel mixture.

Idle Hole Cleaning: Near the engine side of the carb body is a brass tube that dips down into the liquid gasoline. That tube, about 1.5 mm (0.060″) inner diameter and 20mm long, leads to the idle or pilot jet, which is about 0.30 mm (0.012″). The idle jet gets clogged from sitting, then the engine will run but won’t idle. Nothing but a very thin (0.010″) steel guitar string will clean it out. See below about jet drills and cleaning tiny jets. Ultrasonic parts cleaners, carb spray, carb dip, and compressed air are not usually effective. Another way to clean out the idle jet is to 1) place a drill bit that fills the hole (so it does not get crushed), 2) clamp it with a small vise grips, 3) rotate back and forth while pulling, 4) when it comes out, the actual hole is easy to see and clean, 5) press it back in the same way it came out.

Strong solvent is needed to dissolve varnish or tar residue left from years of sitting. Carburetor spray, parts dip, or acetone all help clean out the tar, sometimes with a lot of scraping, brushing or rubbing. Always remember to remove all rubber things first, to not let the rubber touch the solvent. Strong solvents will swell soft rubber, deforming it. Never soak the whole carburetor in strong solvent. In this way, Shaun (at Royal Cyclery and later at Myrons Mopeds) has successfully cleaned out over 100 Honda Express carburetors, without ever replacing any of the rubber gaskets. Part of the reason was they were only sold at Honda dealers, but nonetheless, they are not needed in a normal service or clean-out.

Keihin PA08C-A: This is approximately for a 1979-80 NC50, or maybe NA50. It is identical to a PA08B-B. It has the same white float, non-stirrup float needle, fixed jet, 18mm top threads, and same gaskets. The idle mixture screw type is unknown. No photo available.



7. Keihin
size  carb  model code  years       models
∅12 PA12A-A on #GC6 1981-81 Honda NCZ50 Moto Compo
∅12 PA15A-A on #190 1981-81 Honda NC50 Express (US) xxxxx xxxx 30 mph
∅12 PA16A-A on #193 1981-81 Honda NA50 Express II (US) xxxx xxx  30 mph
∅12 PA13B-A on #187 1981-82 Honda NX50 Express SR (US) xxxx xx  30 mph
∅12 PA13B-B on #GA6 1982-83 Honda NC50 Express (US) xxxxx xoxx 30 mph
∅12 PA13E-A on #GC1 1982-83 Honda NU50 Urban Express (US) xxxx 30 mph
∅12 PA13E-A on #GC1 1982-83 Honda NU50M Urb. Expr. Deluxe (US)  30 mph
∅11 PA25A-A on #GA6 1982-83 Honda NC50AA Express (Iowa) xxxxxx  25 mph
∅11 PA?????   on #GC1 1982-83 Honda NU50AA Urban Express (Iowa)   25 mph
∅10? PA25A-A on#GC1 1982-83 Honda NU50MA Urb. Ex. Deluxe (Iowa) 25 mph



1981 NC50 Express

1981 NA50 Express II

1981 NX50 Express SR

1982 NU50 Urban Express

















#0   16100-GC6-003  Keihin PA12A-A

16010-187-003 gasket set

















#0  16100-190-672
Keihin PA15A-A

#0  16100-193-672
Keihin PA16A-A

#0  16100-187-673
Keihin PA13B-A

















#0 16100-GA6-671
Keihin PA13B-B

#0 16100-???-???
Keihin PA25A-A

#0  16100-GC1-671
Keihin PA13E-A

















Flange Mount: 38 mm hole spacing, 2 x 20 (24 od) o-ring on NC50, NA50 (PA15A-A, PA16A-A, PA13B-B)
Flange Mount: 32 mm stud spacing, 2 x 18 (22 od) o-ring on NX50, NU50, NU50M (PA13B-A, PA13E-A)
Flange Mount: 36 mm hole spacing, 2 x 20 (24 od) o-ring on NC50I, (PA25A-A)

Vacuum-operated automatic choke: These carburetors feature a screw-in main jet, and a built-in vacuum-operated (not electric) automatic choke. When the temperature switch on the head is cold, it allows the engine vacuum to raise the choke plunger up, which opens a new fuel passage, to enrich the mixture during cold starting. As the engine warms up, it closes the vacuum, allowing the thin spring to pull it back down, for normal running. The more precise term for this is “automatic vacuum operated cold start fuel mixture enrichment device”. The 1981-83 automatic choke device itself is not replaceable.

The vacuum source hose has a check ball valve that only allows air flow into the carburetor venturi, and not back out. It needs this even though there is reed valve, because there is still some residual reverse flow caused by the forward and reverse motion of the piston.

The vacuum choke that came out in 1981 did not last long. After 1983, 50cc on-road Honda’s had electric chokes, because they were electric-start scooters with 12 volt batteries.

Identical twins: The PA16A-A looks identical to the PA15A-A. It is on the 1981 Honda NA50 Express II, the final year of that USA-only model. They both have 38 mm flange hole spacing, #75 screw-in jet, 20 mm intake o-ring and the non-stirrup type B float needle. The only difference is the top cable curved pipe. On a PA15A-A it is permanently attached to the screw-on top cap with a swivel joint, while on a PA16A-A the curved cable pipe is detachable.

Intake studs: After 1981 these carbs had studs instead of threaded holes in the mounting flange, except for PA25A-A. PA13B-A and PA13E-A studs are spaced 32 mm with a 18mm intake o-ring. PA13B-B studs are spaced 38 mm, with a intake o-ring 20 mm.

Iowa carb: The PA25A-A is like a PA13B-A, with M18-1.0 top cap threads, 13.0 mm slide, vacuum-operated automatic choke, choke jet in float bowl, tall 2.5 x 1.5 float bowl gasket, intake o-ring 20 mm, 38mm mount spacing, non-stirrup type float and float needle, screw-in main jet size 75. The only noticeable difference is the absence of studs.

Iowa cylinder: The exhaust port is restricted. Here left is 49-state, right is Iowa.

Keihin PA12A-A: This carb from a NCZ-50 has a cable choke like the ’77-79 NC50 carbs. But it has a different part number, 16046-GC6-003 instead of 16046-147-004. Despite that, the NC50 replacement cable choke top and choke pieces fit the NCZ50.



#1 16010-190-004
for 15A 16A 13BB 25A

#1 16010-187-003
for 12A 13BA 13EA

#1  16010-GF8-305 for
for PA 13BA 13EA



















PA 15AA 16AA 13BA 13BB 13EA

      quantity
o# ⇓⇓⇓⇓⇓⇓  PA (a)15AA (b)16AA (c)13BA (d)13BB (e)25AA (f)13EA
o# abcdef price  Honda part#x  description xxx specs
00 1o0000  N/A 16100-190-672 carburetor ’81-81 NC50 PA15A-A
00 o10000  N/A 16100-193-672 carburetor ’81-81 NA50 PA16A-A
00 o01000  N/A 16100-187-673 carburetor ’81-82 NX50 PA13B-A
00 o00100  N/A 16100-GA6-671 carburetor ’82-83 NC50 PA13B-B
00 o00010  N/A 16100-GA6-671 carburetor ’82-83 NC50AA PA25A-A
00 o00001  N/A 16100-GC1-671 carburetor ’82-83 NU50 PA13E-A
01 001001 $24 16010-187-003 gasket solo-set   1b o d g h k
01 110110 $24 16010-190-004 gasket solo-set   1b c d g o k
01 001001 $25 16010-GF8-305 gasket multi-set 1b o d g h k t u
1b 111111 $$8 00000-000-000 top rubber washer 13 x 16.5 x 1
1c 110110 $$2 00000-000-000 intake o-ring 2 x 20 (24 od)
1d 111111 0$2 16176-551-004 idle fuel screw o-ring 1 x 3 (5 od)
1g 111111 $$2 00000-000-000 drain plug o-ring 1.5 x 4 (7 od)
1h 001001 $$2 00000-000-000 intake o-ring 2 x 18 (22 od)
1k 111111 $22 00000-000-000 float bowl gasket 2.5 tall by 1.5 wide
02 0010?0  N/A 16012-187-671 needle set ’81 2a 2b 2c 2d
02 001000  N/A 16012-187-731 needle set ’82 2a 2b 2c 2d
02 1100?0  N/A 16012-193-671 needle set 2a 2b 2c 2d
02 0001?1  N/A 16012-GA6-671 needle set 2a 2b 2c oo 2e
02 0000?1  N/A 16012-GC1-671 needle set 2a 2b 2c oo 2f
2a 111111 0$5 16156-044-004 jet needle w-clip
2b 111111 0$2 16157-044-004 jet needle e-clip for 1.5 clip groove
03 111111 $28 16013-147-004 float set white 3a 3b 3c
3a 111111 $21 00000-000-000 float bare white plastic regular
3b 111111 $$4 00000-000-000 hinge pin substitute Ø2 x 18.5
3c 111111 $$3 0-93600-04006 hinge screw M4x6 sunk phillips
04 1o0000  N/A 16014-190-014 top set NC50 fixed cable pipe M18-1.0
04 o10000 $24 16014-147-014 top set NA50 detachable pipe M18-1.0
04 o01110  N/A 16014-187-013 top set NX50, 82-83 NC50 M18-1.0
04 o00001  N/A 16014-GB2-003
04 o00001  N/A 16014-GB0-831
04 o00001  N/A 16014-098-980 top set NU50 fixed cable pipe M18-1.0
05 110000  N/A 16015-191-034 chamber set deep bowl with choke jet
05 001000  N/A 16015-187-671 chamber set deep bowl with choke jet
05 0001?0  N/A 16015-GA6-671 chamber set deep bowl with choke jet
05 0000?1  N/A 16015-187-043 chamber set deep bowl with choke jet
06 000111 $32 16016-191-004 idle fuel screw set 6a 6b 6f 1d
06 111000 $32 16016-187-003 idle fuel screw set 6a 6b 6f 1d
6e 111000  N/A 00000-000-000 idle fuel mixture screw M6-0.75 special
6b 111111 $$7 00000-000-000 idle fuel mix screw spring Ø5 x 9
6f  111111 $$3 00000-000-000 idle fuel mix screw washer 3.1×5.0x0.5
07 111111 $0016028-187-003
07 111111 $15 16028-GC8-004 idle speed screw and spring 7a 7b
7a 111111 $$4 00000-000-000 idle speed screw M4x19 special
7b 111111 $$2 00000-000-000 idle speed screw spring Ø5.5×10
08 110000 $38 16022-143-620 throttle slide & spring
08 001011  N/A 16022-187-731 throttle slide & spring
08 000101  N/A 16022-191-004 throttle slide & spring
8a 11?? 1? $22 00000-000-000 throttle slide Ø13 #15A
8b 11?? 1? $12 00000-000-000 throttle slide spring Ø9.5 x 42

NC50 idle fuel screw
top: original
bottom: replacement

10 100000  N/A 16118-086-004
10 100000  N/A 16118-166-004 cable rubber boot
10 101110  N/A 16118-187-003 cable rubber boot
10 000001  N/A 16118-GB4-003 cable rubber boot
11 111111 $22 16155-883-005 float needle valve KL 18-4608
12 110110  N/A 16199-435-771 overflow hose 3.0 x 6.5
12 001001  N/A 16199-187-003
12 001001  N/A 16198-HC0-405 overflow hose 3.0 x 6.5
13 001000  N/A 16608-187-000 control hose with check ball 5 x 10
13 110000  N/A 16608-193-670 control hose with check ball 5 x 10
13 000110  N/A 16608-GA6-670 control hose with check ball 5 x 8
13 000001  N/A 16608-GC1-000 control hose with check ball 5 x 8
14 222222 0$1 93892-04012-08 screw & washer M4x12 pan phillips
15 111111  N/A 95002 – 02070   hose clamp B7 vacuum source hose
16 111000  N/A 95002 – 02100   hose clamp B10 for control hose
16 000111  N/A 95002 – 02080   hose clamp B8 for control hose
17 111111  N/A 95002 – 02650   hose clamp B6.5 for overflow hose
18 111111  N/A 95005 – 35001   vacuum (source) hose 3.5 x 7 x 130
19 oo0010 $$7 99101-187-0700 screw-in jet #70 M6-0.75 PAMOA PA25A ? 78-80 Indian, 82-83 NC50I
19 110100 0$7 99101-187-0750 screw-in jet #75 M6-0.75 PA15A 16A 13BB 81-83 NC50, 81 NA50
19 oo1000 0$7 99101-187-0780 screw-in jet #78 M6-0.75 PA13BA 81-82 NX50
19 oo0001 0$7 99101-187-0850 screw-in jet #85 M6-0.75 PA13EA 82-83 NU50





Float Valve Seat: On these carburetors the float seat (the cup that the float needle valve slides in) is carved into the actual carburetor body, and is not replaceable. Polish it with a spinning Q-tip and polish, such as Turtle Wax.

Choke jet: On all of these NC50-type carbs, both shallow and deep-float-bowl versions, there is a choke jet, pressed into a corner of the float bowl. When it gets clogged the engine will only start easily when it is warm.

Verify all jets and fuel or air passageways are open, using wires and or visually with carb spray (wear goggles).

Cable Differences: You can tell what year range a Honda Express is from a distance. A 1977 to 1980 has two cables, a throttle and a choke cable coming straight up from the carburetor.  A 1981 has just a throttle cable coming straight up, but also a vacuum hose for the choke and a float vent hose.  A 1982 to 1983 has a black plastic curved elbow on top, that redirects the throttle cable forward and down, a vacuum hose for the choke, and a vent hose. A 1982-83 also has a different frame, a low headlight, and a two speed transmission.

The Honda Express throttle cable curves rearward and loops downward to get below the carburetor, and then goes forward into the frame tube. The loop design adds friction, but it makes a good clean step-thru frame without any cables or wires hanging out.

1982-83 NC50 hoses

Comparison of PA MOA-A, PA 08B-B, PA 08B-A, and PA 15A-A



















Keihin idle mixture screw channels
Left PA08B-B with idle air screw
Right PA15A-A with idle fuel screw





You can tell the difference between a carb with an idle air mixture screw, and a carb with an idle fuel mixture screw, by the shape of the casting at the top of the float chamber.

















Domino “80s black”

April 2, 2021



Contents:
1. Type B ’80’s Black
2. Type S ’80’s Solex
3. Type A ’00’s Avanti
4. Type P ’80’s Piaggio





1.  Type B Controls

Domino “80’s black” controls were on 1980’s and 90’s mopeds. In the US they were on ’83-86 Trac, ’86 Garelli, and ’86-91 Tomos. The lever blades are black plastic. The cast aluminum housings are black, and have a large empty space for integrated CEV or CEV-compatible switches.


Here is how they look with switches installed. These are Trac switches, not CEV.


Domino 80’s black controls (bottom) compared with 90’s HR Hidria Rotomatika (top) controls used on ’92-07 Tomos. They look the same but almost nothing interchanges. HR switches do not fit Domino and CEV switches do not fit HR.

Brake light switch holes: All type B controls have threaded holes for a brake light switch.

Throttle assist spring: All type B right controls have a throttle assist spring.



Type B Shared Parts


MM#   price     description    specs
Domino# 000  Piaggio#   Type B Shared Parts

000D1  $19.0 sliding block for metal twist tube
0000.00.0000 123392 CNC aluminum remake, wider than D1K

00D1K  $5.00 sliding block for plastic twist tube
1335.91.0000 229935 thinner than D1

000D2  $5.00 pinch screw regular
0107.02.0620 123391,

00D2d  $8.00 pinch screw small head for thumb lever
0000.00.0000 000000 left is D2d, right is D2

000D3  $6.00 screw that holds twist tube
0107.02.0600 123389,

0oD6B  $24.0 twist tube steel 110/140
0000.00.0000 000000 uses D1 sliding block, assist spring type

  D6BL $27.0 twist tube steel 120/150
0000.00.0000 000000 uses D1 sliding block, assist spring type

0oD6K  none  twist tube plastic 110/140
0000.00.0000 000000 uses D1K sliding block, assist spring type

0 D6KL $29.0 twist tube plastic 120/150
0000.00.0000 000000 uses D1K sliding block, assist spring type

000D7  $2-$1 nut for pivot bolt M6-flange
0000.00.0000 121780a,

000D8  $7-$3 pivot bolt M6 x 25 slot
0107.02.0620 121780,

oD11K  $5.00 assist spring brake and start
0800.02.6930 000000,

oD14K  $3.00 brake and start cable anchor
0101.02.0180 123394a has a step ∅8-∅9

00D15  $4.00 clamp cone-tube
0101.02.0180 123394a This has a cone end that digs into the bar.
If loose, then handlebar is worn. Relocate the control on the bar.

00D16  $1.50 clamp bolt M6 x 18 allen
0101.02.0170 123394,

D19K    $25.0 clutch lever black plastic
0000.00.0000 000000 parts are the same as brake lever

D20Kr   $13.0 R lever black plastic
0779.73.4004 000000 24.0 x 135 early type

D20Tr   $15.0 R lever with assist spring
0779.73.4004 000000 24.0 x 135 Tomos #222611

D20Kl   $15.0L lever black plastic
0778.63.4004 000000 24.0 x 135 early type

D20Tl   none  L lever with assist spring
0778.63.4004 000000 24.0 x 135 Tomos #222439

oD21K  $11.0 R grip ∅25 x 110 octa-square
oD22K  $8.00 L grip ∅22 x 110 octa-square
.DKset  $15.0 grip set 110 octagonal-square
1973.82.4004 000000 “pair grips moped”

0D21L  $15.0 R grip ∅25 x 120 texture style
0D22L  $10.0 L grip ∅22 x 120 texture style
.DLset  none  grip set 120 ’80’s texture style
0000.00.0000 000000,

00D23  $13.0 throttle assist spring 4-loop
0518.02.5970 174994,

0D23T $9.00 substitute 3-loop
0000.00.0000 000000 Tomos 223709 for Hidria controls

00G24  $4.00 A1b cable adjuster M5
0511.02.5900 000000 M5-0.8 with thin hex nut

0V29s  $5.50 A3b brake adjuster M6 slotted
0270.02.2580 000000 with nut,

 V29h  $3.00 A2a cable adjuster M6 hex
0000.00.0000 000000 with nut, substitute for V29s

00D35  $12.0 L/R thumb lever ∅5.9 hole
0511.02.5850 000000 ’80’s type for choke or decomp

0D35n  none  L/R thumb lever ∅5.9 hole
1373.02.1554 000000 ’00’s type for choke or decomp

00D36  $2.00 P5a cable pinch bolt ∅5.5 x 8
0101.02.0310 000000,

00D37  none  80’s thumb lever retaining rivet
0000.00.0000 000000 must drill and tap

00D38  $5.00 block-off plate R or L
0711.02.845   000000 for when there is no switch

00D39  $1.50 block off plate screw
0000.00.0000 000000 M3 x 8





Type B Controls and Housings

“bl” means brake light switch hole
“assist” means throttle assist spring
All cable holes threaded-bottomless.
Grips are not included with assemblies.

MM#  price    description
Domino#  perch, lever, grip, slide, screw, tube.

DA7K Domino "80s black" throttle and brake control  BA6  none  R control bl, no lower lever
0000.00  B5L,   D20Kr, D21K, D1,   D2,   D6B,
’85-91 Tomos #222434, steel twist tube

0B5L  $46.0 R housing bl brake/throttle
wide channel for D1 slide, small ID for steel twist tube
Tomos #222612

  BB7  $40.0 L control bl, no lower lever
0904.04  B18K, D20Kl, D22K, MMI#DB8K
’85-91 Tomos #222435, ’93-95 Jawa
’85-89 Trac (kick models)

BB7L  none  L control bl, no lower lever
0000.00  B18K, D20??, D22L
’87-90 Trac DH100

B18K  $32.0 L housing bl, no lower lever
Tomos #222589

DA8K Domino "90s black" throttle and brake controlBA6d  $85.0 R control bl, D35 lower lever
0000.00  B5Ld, D20Kr, D21K, D1,   D2d, D6B, MMI#DA8K
’85-89 Trac mopeds, steel twist tube

B5Ld  $54.0 R housing bl brake/throttle/choke
B5Ld  $40.0 used without choke lever
wide channel for D1 slide, small ID for steel tube, MMI#D5L

DB7K "80s black" brake and start control BB7s  68-52 L control bl, D19K lower lever
0000.00  B18Ks, D20Kl, D22K or D22L, MMI#DB7K
’85-89 Trac (pedal models), D22K grip
’86+ Garelli mopeds, D22L grip

B18Ks $39.0 L housing bl brake/clutch

DA7K Domino "80s black" throttle and brake control  BA7  none  R control bl, no lower lever
0000.00  B5K,   D20Kr, D21L, D1K, D2,   D6K, MMI#DA7K
’86+ Garelli, ’93-95 Jawa, plastic twist tube

BA7L $76.0 R control bl, long, plastic-long
0000.00  B5K,   D20??, D21L, D1K, D2,   D6KL
’87-90 Trac DH100

0B5K  $44.0 R housing bl brake/throttle
thin channel for D1K slide, large ID for plastic tube, MMI#D5K

DB7K "80s black" brake and start control BB7s  68-52 L control bl, D19K lower lever
0000.00  B18Ks, D20Kl, D22K or D22L, MMI#DB7K
’85-89 Trac (pedal models), D22K grip
’86+ Garelli mopeds, D22L grip

B18Ks $39.0 L housing bl brake/clutch

BA7d  none  R control bl, D35 lower lever
0000.00  B5Kd, D20Kr, D21L, D1K, D2d, D6KL
’86-89 Derbi Variant Sport, DS50, plastic throttle tube

B5Kd  none  R housing bl brake/throttle/choke
thin channel for D1K slide, large ID for plastic twist tube

BB7d  none  L control bl, D35 lower lever
0000.00  B18Kd, D20Kl, D22L
’86-89 Derbi Variant Sport, DS50

B18Kd none  L housing bl brake/decomp

BA7w  $68.0 R control bl, wrap-around
0000.00  B5kw, D20Kr, D21K, none, none, D6Kw
wrap-around plastic throttle tube, takes 2-ended cable





BA8d none  R control bl, D35n l0wer lever
1682.03  B5Kn, D20Tr, D21K, D1K, D2, D6K,
plastic throttle tube

BA8dl none  R control bl, D35n lower lever
1741.03  B5Kn, D20Tr, D21L?, D1K, D2, D6KL,
plastic-long throttle tube

BB8d none  L control bl, D35n lower lever
1683.04  B18Kn, D20Tl, D22K or D22L?







2.  Type S Controls

Domino “late Solex” controls were on 1986-88 S 3800 made in France by Motobecane (at right), and the re-make of that, 1999-2005 Solex 3800 made in Hungary by Impex (at left). The throttle is self-closing, unlike most older Solex’s. What’s special is the front (right) brake also controls the throttle (gas). So it has an “either or” mechanism.


fig  price  MM#  description

04  none  SA00   R control assembly no bl

05 none  S500   R housing, no bl switch hole

06 none  0000   twist tube plastic

07 none  S000   R grip 25 x 120

08 none  S800   cursor to brake cable

09 none  S900   cursor to throttle cable

10  $13.0 D20Kr R brake lever

10  $15.0 D20Tr   R lever with assist spring

11 none  S110   throttle cover
12  $3.00 D14K  brake cable anchor pin

13 none  S130   cover screw

14  $7-$3 D800  brake pivot bolt

15  $2-$1 D700  pivot bolt nut M6 flange

16  $1.50 D160  clamp bolt   M6 x 18 allen

17  $4.00 D150  clamp cone-tube

18 none  S180   L housing, no bl switch hole
19  none  SB00   L control assembly no bl

21 none  S000   L grip 22 x 120

22  $15.0 D20Kl L brake lever

23 none  S000   decomp lever

24 none  S000   decomp lever retaining ring





3. Type A Controls

 2000-03 Avanti and Cosmo mopeds are made in India by Mont Motors. The controls, made by Majestic Auto Group (MAG), are remakes of 1980’s and 90’s Domino controls.



2000-01 Avanti Autopower, Mont, Kobra
1. A.EB4s left control has a threaded mirror hole,
long lever, threaded brake switch hole.
3. A.EA4d right control has a threaded mirror hole,
long lever, no brake switch hole, A.D1 sliding block.
2000 Avanti Autopower controls  Avanti Autopower controls 2001 Avanti Autopower controls
’00 Autopower, ’00 Mont, ’00 Autopower, ’01 Autopower, ’01 Kobra



2001-02 Avanti Autopower, Mont, Kobra, Super Sport
2001-02 Cosmo Stinger
2. A.EB4L left control has a threaded mirror hole,
long lever, threaded brake switch hole.
4. A.BA7L right control has a bolt-thru mirror hole,
long lever, threaded brake switch hole, A.D1L slider.
    Cosmo Stinger 2002 Avanti Supersport Avanti Supersport
’01 Autopower, ’01 Autopower, ’02 Stinger, ’02 Stinger, ’02 Stinger, ’02 Stinger





Shared Parts

fig 1234  price  0  MM#  Shared Parts

00 1100none  D22A   left grip
01 0011none  D21A   right grip
01 1111none  DAset  grip set 120mm
Domino 2166.82

02 0010none  A6BL   twist tube steel ∅25 x 120/150
02 0010$27.0 D6BL   twist tube steel ∅25 x 120/150

02 0001none  A6KL   twist tube plastic ∅25 x 120/150
02 0001$29.0 D6KL   twist tube plastic ∅25 x 120/150

03 0011$13.0 D23 0  throttle assist spring 4-loop
03 0011$11.0 D23s substitute 3-loop Tomos 223709

04 0010none  A1 00  slider original
04 0010$19.0 D1 00  slider substitute?

04 0001none  A1K 0  slider original
04 0001$5.00 D1K 0  slider substitute?

05 0011$5.00 D2 00  slider pinch screw

07 0011none  A20LR right lever black long

08 0011$6.00 D3 00  twist tube retainer screw

11 1000$1.50 D17 0 clamp bolt M6 x 20 allen
0117.02.1070 123395,

12 1111$5.50 V29 0 A3b brake adjuster M6 slotted
0270.02.2580 000000 with nut, for Vespa and others

12 1111$3.00 V29h    A2b cable adjuster M6 hex

12 1100$4.00 G24 0 A1b throttle adjuster M5
0511.02.5900 000000 with thin hex nut

13 2211$3.00 D14K   cable anchor pin

14 2211$2-$1 D7 00  nut for pivot bolt

14 1111$7-$3 D8 00  brake pivot bolt M6 x 25 slot

15 1000$3.00 D13 0  start pivot bolt M6 x 23 slot

15 0100$7-$3 D8 00  start pivot bolt M6 x 25 slot

19 0000$11.0 A20KL L lever short for assist spring

19 1100$13.0 A20LL L lever long for no assist spring

21 1111$4.00 D150  clamp cone-tube

23 0111$1.50 D16 0 clamp bolt M6 x 18 allen
0101.02.0170 123394,

24 1100$25.0 D19K  clutch lever black plastic
0000.00.0000 000000 parts are the same as brake lever



Controls and Housings

fig   price  0  MM#  Controls and Housings
Domino# 0000 perch, lever, grip, slide, screw, tube.

A   none  A.GA6d R control no bl,
0000.00.0000 A5ade, A20Ll, D21A, A1, D2, A6BL
’00-01 Avanti Autopower, Mont, Kobra

10 none  A5ade R housing, no bl hole
10 $69.0 D5adb R housing bl

A   none  A.BA7L R control bl,
0000.00.0000 A5K, A20Ll, D21A, A1K, D2, A6KL
’01-02 Avanti Autopower, Mont, Kobra, Super Sport
’01-02 Cosmo Stinger

10 none  A5K 0  R housing bl late
10 $44.0 B5K 0  R housing bl

B   Cosmo Stingernone  A.GB5   L control bl
0000.00.0000 A18b, A20Lr, D22A,
’00-02 Avanti Autopower, Mont, Kobra
’01-02 Avanti Super Sport, Cosmo Stinger

22 none  A18b  L housing bl
22 $26.0 G18b  L housing bl









4. Type P Controls



1980 Piaggio Ciao PX (US), 1980 Si (US), 1982 Si (US)



Piaggio Models:   with blinkers /B
one speed M, variable speed V
Belgium-B, Sweden-S, Norway-N, USA-US .
1. ’84-85 Bravo EML, EVL, Si SIM, SIV  (no brake light)
2. ’80-85 Ciao PX C7E-US, ’79-93 Si SIV-US
3. ’84-85 Bravo EML/B-B, EVL/B-B, Si SIV/B, SIM/B-S
4. ’84-85 Si SIV/B  (no brake light)


fig 1234MM#  price  description
Domino# 000  Piaggio#

A  10000PAe  none  R control black
0000.00.0000 188057,
no stop switch hole, no switch mount, no assist spring

A  0100PAsg   $45.0 R control gray assist
0000.00.0000 189824,
with stop switch hole, square switch mount, assist spring
switch is shown but not included

A  00100 PA   none R control black
0000.00.0000 188562,
with stop switch hole, lower button mount, no assist spring

A  0001PA1e  none R control black
0000.00.0000 212517 remake
no stop sw hole, lower horn button, no assist spring

B  10000PBe  none L control black
0000.00.0000 188056,
no stop switch hole, no switch mount

B  01000PBg  none L control gray
0000.00.0000 189022,
with stop switch hole, lower button mount, thumb lever

B  00100PBs  none L control black square
0000.00.0000 189044,
with stop switch hole, square switch mount

B  0001PB1e  none L control black
0000.00.0000 212519,
no stop switch hole, no switch mount

01 1111D21c none  R grip ∅24 x 114 Piag oct 18526
00 1111D22c none  L grip ∅22 x 114 Piag oct 18527
00 1111Dsetc grip set 114 Pia. octagon
1934.82.0000 188526-18527 Piaggio Ciao, Si to ’88

02 101100D6 $21.0 twist tube steel
0000.00.0000 123393 100 x 125 plain type

02 01000D6a 21-16  twist tube steel
0000.00.0000 174993 100 x 130 assist type with flange

03 101100D4  $5.00 grip washer
0000.00.0000 123390,

04 111100D1 $19.0 sliding block
0000.00.0000 123392 new CNC alum. remake

05 111100D2 $5.00 pinch screw
0107.02.0620 123391,

06 2222oD11K  $5.00 brake lever assist spring
0800.02.6930 177072,

07 1111P20R $16.0 right brake lever
0799.73.4004 177340 24.0 x 137

08 111100D3 $6.00 twist tube screw
0107.02.0600 123389,

09 01000D23 $13.0 assist spring 4-loop
0518.02.5970 174994,
09 0100D23s $9.00 substitute spring 3-loop
0000.00.0000 000000 Tomos 223709

P type right housings:
M6 thread brake cable hole, threadless throttle cable hole

10 10000P5e  none  right housing black
no stop switch hole, lower switch mount, no assist type
0000.00.0000 188059,

10 0100P5sg  $28.0 right housing gray
stop switch hole, square switch mount, assist spring type
0000.00.0000 189825,
takes M3-0.5 x 22 sunk-head switch screws

10 001100P5  none  right housing black
no stop switch hole, lower switch mount, no assist type
0000.00.0000 212518,



11 11110D16 $1.50 right clamp bolt M6 x 18 allen
0101.02.0170 123394,

12 22220V29 $6-$4 A3a brake adjuster M6 round
0000.00.0000 103964 with nut, for Vespa

12 2222V29s  $5.50 A3b brake adjuster M6 slotted
0270.02.2580 000000 with nut,

12 2222V29h A2a cable adjuster M6 hex
0000.00.0000 000000with nut, substitute

13 2222D14K $3.00 brake/start anchor pin
0101.02.0180 177073 has a step ∅8-∅9

14 222200D8 $7-$3 brake pivot bolt M6 x 25 slot
0107.02.0620 121780,

14 222200D7 $2-$1 brake nut M6 flange
0000.00.0000 121780a,

15 11110D13 $3.00 start pivot bolt M6 x 23 slot
0101.02.0020 121781,

15 111100D7 $2-$1 start nut M6 flange
0000.00.0000 121780a,

19 1111P20L $16.0 L brake lever black plastic
0798.63.4004 176945 24.0 x 137

21 22220D15 $4.00 clamp bolt cone-tube
0101.02.0180 123394a,

P type left housings:
M6 thread brake cable holes, threadless start cable hole

22 10000P18 none  L housing 2-lever black
0000.00.0000 188058,
no stop switch hole, plain (no switch mount)

22 0100P18g $13.0 L housing 2-lever gray
0000.00.0000 189021,
with stop switch hole, diamond mount for horn button

22 0010P18s none  L housing 2-lever black
0000.00.0000 189043,
with stop switch hole, square mount for blinker switch

22 0001P18? none  L housing 2-lever black
0000.00.0000 212520,
no stop switch hole, square mount for blinker switch

23 11110D17 $1.50 left clamp bolt M6 x 20 allen
0117.02.1070 123395,

24 11110P19 $16.0 start (decomp) lever
0511.02.5850 176946 black plastic ∅6 x 8 cable end









Domino Menu

April 2, 2021

Select which control family:

60’s – 80’s

80’s black

80’s – 90’s

90’s – 00’s







Domino

Domino controls (comandi) are made in Italy since the 1950’s. Domino controls are found on most Italian mopeds, such as Arciero, Aspes, Baretta/Piccoli, Beta, Bianchi, Cimatti, Concord/Fantic, Demm, Gadabout, Garelli, Malaguti, Motobecane Sebring, Motomarina, Motron, Negrini, Pacer/Italtelai, Snark, late 80’s Tomos, and Vespa/Piaggio. Other Italian mopeds had PV, OSL, or Ci.Ti controls. Domino has made, and still does make, many other high quality motorcycle controls.

1982 MMI parts list
for 1970-77 controls

MMI Part Numbers: In 1982 the biggest USA moped part importer/distributor Marina Mobili Inc assigned Domino part numbers that began with “D”. The “D” parts were for sale to the public through all moped dealers.

MM Part Numbers: Domino also made controls specifically for Vespa and Garelli. Those parts were only sold through Vespa or Garelli dealers. They never did have a MMI part number. Myrons Mopeds made up the “V” and “G” part numbers to agree with the corresponding “D” part numbers used by MMI.

Families: The control parts are organized into families, based on the way the cables attach.

Brake light switch holes: Many non-US models do not have brake lights. So their Domino housings don’t have threaded holes for brake light switches. Their Domino “70’s chrome” levers do not come with the inner push plate that pushes the button on the brake light switch. Their lever blades do not have the extra little hole punched in them to anchor the inner push plate. Here all of the housings and levers are for US-models with a brake light, unless noted.

Prices: green means new. dark green means used, n.a. means not available. Used items are cleaned, lubed, checked and in good or usable condition unless stated otherwise. Control assembly prices do not include hand grips or electrical switches, unless stated otherwise.

Mostly slide type throttles: Most of the throttles shown here are the sliding block (cursor) type, where the twist tube (barrel) has a spiral slot that moves a sliding block back and forth. The sliding block contains a set screw that secures the throttle cable inner wire. The throttle cable exits parallel to the handlebar. The advantage of slide type throttles is they use a single ended universal-type throttle cable that is easy to get and replace. The disadvantage is they can’t pull the cable very far, so they are only used on very small carburetors like mopeds and mini-cycles have.

Some wrap around throttles: Only some throttles shown here are the wrap around type, where the cable wraps around the twist tube. The throttle cable exits perpendicular to the handlebar. The advantages of wrap around type throttles are they stick less and can pull the cable farther. The disadvantage is they require a double ended throttle cable, which is specific to the carburetor and the cable pipes.

< One ended throttle cable

< Two ended throttle cables

These throttles need occasional lubrication (oil or grease), or they become sticky and eventually wear out. Because the twist tube is steel and the sliding block is aluminum, it’s the sliding block that wears out the most. Even with lubrication, a worn sliding block causes the throttle to stick, where it does not snap back when you let go. After 1978, they had a helper spring on the twist tube. This made them not stick as much, or not at all.

Twist Tubes (throttle barrels): Domino made improvements to the twist tube and slider every 10-15 years. In the 1960’s and early 70’s the D6 and D6L steel twist tubes used a D1 slider and had no assist spring flange. In 1978 a throttle return assist spring was added. The D6a and D6aL steel twist tubes had a flange with a spring anchor slot. The part where it goes inside the housing was longer. At first only deluxe models had an assist spring, but by the 1980’s all moped models did. In the 1980’s a new family of all-black controls came out, with built-in (integrated) switches. The twist tube retaining screw had to be relocated to make room for the switches. It was moved from the top near the grip to the bottom near the clamp bolt. D6B and D6BL steel twist tubes had slots for both the new and old retaining screw locations. Also in the 1980’s the twist tube changed from steel to non-stick plastic, and slider changed from D1 to D1K. There were two versions D6N and D6NL with no assist spring, and two versions made for an assist spring D6K ands D6KL. Understanding the twist tube is the key to understanding the control families.





Domino, MMI and MM Part #’s



Domino, Marina Mobili Inc. (MMI) 1980’s, and Myrons Mopeds (MM) 2020’s.

Domino# MMI# MM#    all levers have ball ends

0300.03  0000   DA0     silver plain bl ribbed
0000.00  DA1    DA1     silver plain bl waffle
0000.00  D5      D5 00  housing xx bl
0000.00  0000   DB0     silver plain bl ribbed
0000.00  DB1    DB1     silver plain bl waffle
0000.00  D18    D18 0  housing xx bl

0000.00  0000   VA1     silver plain bl ribbed
0431.03  0000   VA1     silver plain no bl ribbed
0000.00  0000   V5 00  housing xx bl
0000.00  0000   VB1     silver plain bl ribbed
0199.06  0000   VB1     silver plain no bl ribbed
0000.00  0000   V18 0  housing xx bl

0000.00  0000   DA0d   silver diam bl ribbed
0286.03  0000   DA0d   silver diam no bl ribbed
0000.00  0000   D5d 0  housing xx bl
0000.00  0000   DB0d   silver diam bl ribbed
0000.00  0000   DB0d   silver diam no bl ribbed
0000.00  0000   D18d 0housing xx bl

0000.00  DA1A  DA1b   black  plain bl
0000.00  D5A    D5b     black  plain bl
0000.00  DB1A  DB1b   black  plain bl
0000.00  D18A  D18b   black  plain bl

0000.00  DA3B  DA1db black  diam bl
0000.00  D5B    D5db
0000.00  DB3B  DB1db black  diam bl
0000.00  D18B  D18db

0000.00  DA3    DA2    silver plain bl assist
0000.00  0000   D5a
0000.00  DB3    DB2    silver plain bl
0000.00  D18    D18

0000.00  DA4B  DA2b  black  plain bl assist
0000.00  0000   D5ab
0000.00  DB4B  DB2b  black  plain bl
0000.00  0000   D18b

0000.00  0000   DA3b  black  diam bl assist
0000.00  D5C    D5adb
0651.06  0000   DB3b  black  diam bl
0000.00  D18C  D18db

0000.00  DA3M DA3m black  diam bl assist
0000.00  D5C    D5adb long lever
0000.00  DB3M DB3m black  diam bl
0000.00  D18C  D18db long lever



Garelli and MM Part #’s


page 10  ’77 Sport
01  506851.0142 L control  gB1 silver plain no-ball lever
03  506851.0131 R control  gA1 silver plain no-ball lever
32  506351.5212 L housing G18 silver plain

page 10  ’77-78 Sport
01  506852.0142 L control  GB1d silver diamond
03  506852.0131 R control  GA1d silver diamond
32  506852.5212 L housing G18d silver diamond

page 21 ’77 Gran Sport
page 34 ’77 Super Sport
01  506901.0142 L control  GB1 silver plain
03  506901.0131 R control  GA1 silver plain
32  506351.5212 L housing G18 silver plain

page 65  ’76-78 Gulp
00  506901.0142 L control  GB1 silver plain
00  506901.0131 R control  GA1 silver plain
02  506351.5212 L housing G18 silver plain

page 80  ’76-77 Eureka
page 95  ’75-76 Eureka
00  506351.0142 L control  GB1 silver plain early grip
00  506351.0131 R control  GA1 silver plain early grip
02  506351.5212 L housing G18 silver plain

After late-77 all throttle controls had an assist spring.

page 21 ’77-79 Gran Sport, Ltd, Rally Sport
page 34 ’77-79 Super Sport, Ltd
01  506903.0142 L control  GB2d silver diamond
03  507251.0131 R control  GA2d silv diam assist
32  506852.5212 L housing G18d silver diamond

page 50 ’77-79 VIP
01  506903.0142 L control  GB2d silver diamond
03  507251.0131 R control  GA2d silv diam assist
32  506852.5212 L housing G18d silver diamond

page 141 ’80-82 VIP
36  506903.0142 L control  GB2d silver diamond
37  507251.0131 R control  GA2d silv diam assist

After ’81 all controls were black with longer levers and grips.

page 115/1 ’80-83 Sport, Rally Sport, Ltd, 2sp
31  507991.0142 L control  GB3m black diamond
32  507991.0131 R control  GA3m blk diam assist

page 126/1 ’80-83 Super Sport XL, Ltd, Ltd 2sp
31  507991.0142 L control  GB3m black diamond
32  507991.0131 R control  GA3m blk diam assist

page 154 ’83-84 Monza GT
30  507991.0142 L control  GB3m black diamond
31  507991.0131 R control  GA3m blk diam assist



1978 Domino Catalog

Domino part#: black is in 1978 Catalog, red is an add-on

ba = brake adjuster, ta = throttle adjuster, sa = start adjuster
bl = brake light, hb = horn button, bh = holes for switch base
oval = oval-diamond switch base, rect = rectangular switch base


rg  = Normale    (ribbed grip)  105 black
rg  = Normale    (ribbed grip)  105 grey
wg = America    (waffle grip)   105 black
lg   = America    (long waffle)  120 black
tg  = Motocross (texture grip) 120 black
tg  = Motocross (texture grip) 120 gum



. no bl x no bl   with bl  Right Control 140
chrome  nylon  chrome  < 140 lever ball-end, 105 grip
181.03 800.03 300.03 slide 20mm cable pull, Turismo
286?03 802.03 000.03 slide rg oval
431.03 818.03 000.03 slide rg ba
207.03 825.03 000.03 slide rg ba, oval
287.03 824.03 000.03 slide rg ta, oval Garelli
198.03 000.00 000.03 slide rg ba, hb Piaggio
195.03 000.00 000.03 slide rg, thumb lever
484.03 000.00 000.03 slide rg, rect
530.03 823.03 000.03 slide rg ta, Garelli
433.03 813.03 000.03 wrap rg, 25mm cable pull, Sport
412.03 000.00 000.03 wrap rg, thumb lever

. no bl x no bl   with bl  Right Control 155
chrome  alum.  alum.    < 155 lever ball-end, 120 grip
000.03 392.03 000.03 slide tg assist ba ta, Jr, oval
378.03 000.03 000.03 slide tg assist ba ta, Std, oval
000.03 348.03 000.03 slide tg assist ba ta, Jr
377.03 000.03 000.03 slide tg assist ba ta, Std
000.03 291.03 000.03 wrap tg ba, Junior
349.03 000.03 000.03 wrap tg ba, Standard
000.04 304.04 000.04 R lev tg ba Junior
338.04 000.04 000.04 R lev tg ba Standard

. no bl x no bl   with bl  Left Control 140
chrome  nylon  chrome  < 140 lever ball-end, 105 grip
288.06 801.06 000.06 2 lev rg 140    Minarelli
352?06 814.06 000.06 2 lev rg 115    Morini
447.06 000.00 000.06 2 lev rg   70    Puch
295?06 815.06 000.06 2 lev rg 115 sa Garelli
199.06 000.00 000.06 2 lev rg   70 ba Piaggio
446.06 000.00 000.06 2 lev rg   70 ba oval
350.06 000.00 000.06 2 lev rg 115 ba sa
500.06 803.06 000.06 2 lev rg 140 sa Garelli
297.06 000.00 000.06 2 lev rg 100 ba Benelli
510.06 000.00 000.06 2 lev rg 100
472.06 000.00 000.06 2 lev rg 115 ba oval, black
000.06 000.00 651.06 2 lev wg 115    oval, black
489.06 825.06 000.06 2 lev rg 115 ba
186.04 805.04 000.04 L lev rg
198.04 000.04 000.04 L lev rg ba Benelli
432.04 819.04 000.04 L lev rg ba
434.04 000.04 000.04 L lev rg ba, decomp
445.04 000.04 000.04 L lev rg ba oval, black

. no bl x no bl   with bl  Left Control 155
chrome  alum.  alum.    < 155 lever ball-end, 120 grip
000.04 295.04 000.04 L lev tg ba Jr
376.04 000.04 000.04 L lev tg ba Std
000.04 347.04 000.04 L lev lg ba Jr
332.04 000.04 000.04 L lev lg ba Std
000.04 310.04 000.04 L lev lg ba bh Jr
218.04 000.04 000.04 L lev lg ba bh Std









Other Dellorto

March 19, 2021

Dell’Orto ME18-BS

Dellorto ME18-BS

This carburetor was on a 1965-66 Harley Davidson M50, made in Italy by Aermacchi.

∅23 clamp diameter
68 jet, cleaned with 0.027″ wire
40 idle jet cleaned w/0.016″ wire
has idle fuel mixture screw
Z58A needle jet

Dellorto ME18-BS







Dell’Orto UA and MA late

Dellorto UA19 S “late” Minarelli # M42-116



 # Dellorto#
01  04884 throttle slide
02  00000 throttle needle
03  00000 atomizer
04  01486 main jet 5mm (specify size)
05  00000 x
06  01607 float needle only
07  00000 x
08  03076 float assy
09  01427 screw-on top
10  01481 cable adjuster
11  01692 adjuster lock nut
12  01642 carb top
13  03570 choke clip
14  01409 throttle slide spring
15  01407 throttle needle clip
16  08128 clamp nut
17  08129 mount clamp
18  00000 clamp bolt
19  13910 clamp sleeve 23 id x 26 od
20  00000
21  00000
22  00000
23  00000
24  00000
25  00000
26  00000
27  00000
28  00000
29  00000
30  00000
31  00000
32  00000
33  00000
34  00000
35  00000
36  00000
37  00000
38  00000
39  00000



Dell’Orto UA19-S early

















Dellorto PHVA

March 19, 2021

Dell’Orto PHVA14

Welcome. This is a “third generation” Tomos carburetor, on US mopeds. It is preceded by two others, the Encarwi A83 on Tomos A3 1974-85, and the Dellorto SHA 14-12P on Tomos A3 1986-91 and A35 1992-06.



Dellorto PHVA14 Tomos A55 carburetor four views



Dellorto PHVA14 parts

0     N/A     233730 carburetor PHVA 14 DD  right side, no drain
1      243115 rubber boot for cable
2     $6.00 243116 adjuster with nut M5-0.75
3     $8.00 243152 throttle cable guide 72º
4     $1.00 243118 carb top screw M5-0.80 x 14
5     N/A     243119 carburetor top cover
6     N/A     set only rubber “figure 8” gasket   see 40 below
6     N/A     set only paper kind shown, actual kind is rubber
7     N/A     243120 throttle spring Ø12 x 52
8     N/A     243121 throttle slide insert
9     N/A     243103 throttle slide #40 Ø15
10   $2.00 243122 needle E-clip for 1.5 clip groove
10a $2.00 phva10 substitute E-clip 1.5 mm
11   $30.0 243104 jet needle A07 2.0-1.0 x 38
11a $8.00 phva11 subst. needle  2.0-1.1 x 38
2.0 needle with 1.5 clip grooveDellorto PHVA throttle needle and substitute
“1.5” clip is 1.3 mm at opening

13   N/A     243125 choke lever bare
14   $4.00 phva14 rubber o-ring 18 x 20
15   $0.80 243123 screw M4-0.70 x 10
16   N/A     243124 clamp for choke lever
17   N/A     243151 choke Assy 13,14,15,16
18   $8.00 243126 spring idle air Ø5 Ø7 x 9
19   $18.0 243147 idle air screw M5-0.50
21   $8.00 243128 spring idle speed Ø5 Ø7 x 14
22   $18.0 243148 idle speed screw M5-0.80
23   $17.0 243106 needle housing 209GA
23a $15.0 phva23 needle housing 210GA
24   $8.00 243160   main jet 55 M6-0.75 original A55
24a $6.00 D64x052 main jet 52 M6-0.75
24b $5.00 D64x058 main jet 58 M6-0.75
24c $5.00 D64x060 main jet 60 M6-0.75
26   $8.00 243222       idle jet 25 M4-0.70 original A55
26a $8.00 D11600x29 idle jet 29 M4-0.70
26b $8.00 D11600x30 idle jet 30 M4-0.70
26c $8.00 D11600x32 idle jet 32 M4-0.70
26d $8.00 D11600x40 idle jet 40 M4-0.70
28   $6.00 243162 choke jet 40 M5-0.80
30   $25.0 243114 float all plastic bare
31   $45.0 243149 float with needle valve
32   $35.0 243131 float needle valve
34   N/A     set only float rubber o-ring  bigger than SHA
35   $7.00 243132 float hinge pin Ø2.0 x 19.5
36   N/A     243150 float bowl plastic

Dellorto PHVA Gaskets

Dellorto 52622 PHVA Gasket Set
Right: 6,14,34    Left: others

37  $0.80 027057 screw M4-0.70 x 18
40  $15.0 236460 gasket set 6, 14, 34
—   $16.0 D52622 gasket set 6, 14, 34, others
—   $5.00 others   gasket set others
45  $35.0 233740 intake silencer assy
46  $5.00 233741 air filter foam
47  $18.0 233748 junction sleeve   see note below
48  $2.00 221584 clamp 32-50







Notes

Junction sleeve 233748 on Tomos A55 models contains an air restrictor. Without derestriction, and with the stock catalytic exhaust, the stock jet is too big. Too much unburned fuel and oil are produced. That causes black goo to drip from the exhaust outlet, and soon clogs the catalytic converter.

With derestriction, the stock jet size #55 becomes correct. The catalytic exhaust outlet stays super clean. No visible smoke is emitted. Only occasional water dribbles out, just like in modern cars.

233748 joins carb and air filter

233748 A55 junction sleeve

233748 derestricted



















Intake silencer 23340 on Tomos A55 models does more than just reduce noise. It reflects sound waves in a way that recovers or re-captures the mist of fuel and air that flows outward every down stroke of the piston. Remove the air box and a bigger jet is required. Less torque is produced and some fuel is wasted and gets on the rider’s right leg. Besides the magical shape and volume, the stock air box draws air from inside the frame. That air is at a slightly higher pressure than the moving air outside. Tomos engineers made the A55 engine super efficient in order to meet emissions standards in many countries. In doing that, too much power was produced, so restriction was needed to meet power and speed limits.



Dellorto Service

March 18, 2021



Choke Sticking On: Often the choke sticks on, for no apparent reason. The throttle cable is sometimes too loose to pull up the choke trigger. More often, the choke trigger lever has become bent or twisted. This happens often because great care must be taken to keep the trigger against the side wall when the top assembly (throttle slide, choke trigger, cover assembly) is installed. Before the top screws are tightened, and with one finger holding the top in proper position, it is wise to test the choke by directly pulling on the throttle wire. It should click off at full throttle. Only then should the screws be gently tightened, while holding the top with that finger. If not, then inspect the trigger lever for misalignment, and re-align carefully with small pliers. Sometimes rounding off the side edges helps the trigger lever to not stick also. The last resort is to replace it, but pushing out the tiny hinge pin is difficult. So it is better to straighten it.





The Dellorto SHA idle hole is in the silver zinc body, at the base of the brass spray tube

Cleaning a Dellorto idle hole with a tiny #71 drill and a pin vise

Cleaning a Dellorto idle hole with a tiny #71 drill and a pin vise

















Here is the engine side view of a Delorto SHA carburetor. At the base of the vertical brass “spray tube” with one or two holes in it, there is a tiny hole in the silver metal below the brass. It gets overlooked frequently. When it is blocked, the engine will not stay idling for more than a few seconds, but will otherwise run fine if the throttle is kept open.





Dellorto Jets

March 18, 2021



4, 5, or 6 millimeter

Thread Size: Dellorto jets in mopeds come in three thread sizes 4, 5, and 6 millimeter. Each thread size has maybe a hundred different jet sizes. They all fit and look the same but have different size pin holes.

Left, genuine (with “diamond INC” logo)
Right generic (with different or no logo)

Jet Number: Jets have a number stamped on them indicating the hole size. The number can have different meanings for different jet makers.

For generic Dellorto jets the jet number is the mm size.
A generic Dellorto 60 is 0.600 mm.

For genuine Dellorto jets the jet number is less than the mm.
A genuine Dellorto 60 is 0.627 mm.

So a genuine 60 is in-between a generic 62 and 63.
This sounds wrong but is true!





Dellorto Jet Sizes Graph, drawn in 2002

How this was determined: Here is a graph of 17 genuine Dellorto 5mm jets actual sizes. The direct measurement was done with a set of machinists wire gauges, in increments of 0.001″. You can see how the measured sizes fall nicely on two lines. The line for over-56 has less slope than the line for under-56. You can also see what drill sizes correspond to what jet sizes. This study was done in 2002 before there were generic jets. It was surprising to learn that the stamped number did not mean the millimeter size.

Dellorto Jet Sizes Graph, improved in 2019



Genuine 6413 (6 mm) Jets (M6-0.75 thread)
genuine       closest generic
##  inch size mm   ##     price    applications
51 0.0215″=0.550  55  $4.00 generic 55 (= Dellorto 51)
52 0.0219″=0.556  56  $6.00 A55 smaller for high altitude
54 0.0228″=0.580  58  $4.00 generic 58 (= Dellorto 54)
55 0.0231″=0.587  59  $8.00 Tomos A55 243160 original
56 0.0236″=0.600  60  $4.00 generic 60 (= Dellorto 56)
58 0.0242″=0.615  61  $5.00 generic 61 (= Dellorto 58)
59 0.0244″=0.620  62  none   generic 62 (= Dellorto 59)
60 0.0247″=0.627  63  $5.00 generic 63 (= Dellorto 60)

Genuine 1486 (5 mm) Jets (M5-0.75 thread)
genuine       closest generic
##  inch size mm   ##    price    applications
42 0.0178″=0.451  45   $5.00
43 0.0182″=0.462  46   none   pre-78 Ciao & Bravo
00 0.0182″=0.462  46   $5.00 generic 46 = Dellorto 43
44 0.0186″=0.472  47   $5.00
45 0.0190″=0.483  48   none   78-on Ciao & Bravo
46 0.0194″=0.493  49   $5.00
47 0.0198″=0.503  50   $7.00
48 0.0202″=0.513  51   $5.00 most 20mph mopeds
49 0.0207″=0.525  52   $7.00 78-83 Vespa Grande

50 0.0210″=0.533  53   $5.00 76-80 Garelli (some)
51 0.0215″=0.546  55   $7.00 85-91 Tomos A3
52 0.0219″=0.556  56   $5.00 almost all 30mph mopeds
53 0.0223″=0.566  57   $7.00 92-06 Tomos A35
54 0.0227″=0.577  58   $5.00 86-90 Derbi (flat reed)
54 0.0227″=0.577  58   $3.00 generic jet, no INC logo
55 0.0231″=0.587  59   none
56 0.0235″=0.597  60   $5.00
57 0.0239″=0.607  61   $7.00
58 0.0242″=0.615  62   $5.00
60 0.0247″=0.627  63   $5.00
62 0.0255″=0.648  65   none
64 0.0262″=0.665  66   none
66 0.0268″=0.681  68   none
68 0.0274″=0.696  70   none
70 0.0280″=0.711  71   none

Genuine 11600 (4 mm) Jets (M4-0.70 thread)
genuine       closest generic
##  inch size mm   ##   price    applications
25 0.0107″=0.272  27  $8.00  Tomos A55 pilot jet
29 0.0124″=0.314  31  $8.00
30 0.0128″=0.325  33  $8.00  good for A55 pilot jet
32 0.0140″=0.355  35  $8.00  same as #80 drill
35 0.0149″=0.378  38  N/A
40 0.0170″=0.431  43  $8.00
42 0.0178″=0.451  45  N/A
44 0.0187″=0.475  47  N/A
45 0.0190″=0.483  48  $8.00
48 0.0202″=0.513  51  $8.00  Sachs 504/1A and 505/1A
50 0.0210″=0.533  53  N/A
55 0.0230″=0.580  58  $8.00
60 0.0250″=0.635  63  $8.00



Clone Carbs: Some Dellorto SHA clone carburetors have a different jet thread, M5-0.8. But the Runtong (China) SHA clone has the same thread M6-0.75.



Dellorto SHA 12.xx 13.xx

March 18, 2021

The Dellorto SHA 12.xx 13.xx carburetor family is like the SHA 14.xx 15.xx family, but more compact. They have a smaller air filter flange, 50mm instead of 58. This style of carburetor was original on all Vespa/Piaggio mopeds 1970’s, 1980’s, 1990’s, and 2000’s. In the USA it was on 1972-86 Vespa mopeds, 1983-86 Garelli VIP-N, and mid 1990’s Kinetic TFR mopeds.

Improved choke: These carburetors have an improved choke release trigger, that cures the sticking trigger lever problem that the 14.xx 15.xx SHA has. Vespa types have a sliding push rod, that moves up a ramp in the throttle slide when the throttle is raised fully. The solid rod pushes the choke lever/plate over a little stop tab. The torsion spring is then free to snap it back off. The top is relatively easy to put on, with only the throttle slide and spring to install, no choke device that gets damaged easy.



Vespa (Piaggio) Carburetors


On 1972-79 Vespa mopeds (US models) there were 3 carb bodies, 7, 10, and 12mm, 5 jet sizes, 39, 41, 43, 45, 49, and 2 air filter boxes, 3-hole and 6-hole. The Boxer had a side-pull carb top assy, like Peugeot. It gives more frame clearance. After 1979 the Boxer became the Si. There were 4 choke levers, Grande, Bravo, Ciao, Boxer. The later Boxer 2 had the linkage type choke with pull wire.



1980s Vespa Carburetors
On 1980-83+ Vespa mopeds (US models) there are 3 carb bodies, 7, 10, and 12mm, 4 jets, 39, 42, 45, 49. The Ciao P and Bravo P had top pull, and Si had a side-pull carb top assy. There are 3 choke levers, Bravo-Ciao, and Si, linkage type, and Grande. There are 2 air filter boxes, 3-hole and 6-hole. Some are newer designs.



’78-83 Dellorto SHA 12.7 has a lever choke (4 types),
18 mm clamp, 16 sleeve, jet 39
’00-  Original on 00    part#   jet# .
’78-80 Ciao 20, 00     114338  39
’78-80 Bravo 20, 25   141902  39
’78-83 Grande 20  00 307174  39
’80-83 Ciao PX 20 00 177647  39
’79-83 Si 20  00 xxxx 191230  39

’72-83 Dellorto SHA 12.10 has a lever choke (4 types)
18 mm clamp, 16 sleeve, jet 41, 42, 43, 45 or 49.
’00-   Original on 00    part#   jet# .
’72-77 Ciao 25   , 00   113344  43
’77-77 Bravo 25, 00    131258  43 short choke lever
’78-80 Ciao 25, 30      182378  45
’78-80 Bravo 30 , 00   157180  45 short choke lever
’80-83 Ciao PX 25, 00 188327  42
’80-83 Ciao PX 30, 00 157501  49
’79-83 Si 25  00  xxxx 191863  41
’79-83 Si 30  00  xxxx 168549  43

’60-90 Dellorto SHA 12.12 has a lever choke,
18 mm clamp, 16 sleeve, jet 49.
’00-  Original on 00    part#   jet# .
’78-83 Grande 25, 30 353881  49



Replacement Carburetors


Dellorto SHA 12.10 has a pull-wire choke,
18 mm clamp, 16 sleeve, jet 42  $70.0 .
transfer the choke lever from the old carb




Dellorto SHA 12.12 has a pull-wire choke,
18 mm clamp, 16 sleeve, jet 51  $73.0 .
transfer the choke lever from the old carb





Carburetor Parts

Prices in green are for new, dark green are for used items.

#  Piaggio# price    description            remarks
00 000000 $48.0 SHA 12/12 bare body  Grande 25 & 30mph
00 000000 $40.0 SHA 12/10 bare body  Ciao, Bravo, Si 25 & 30mph
00 000000 $38.0 SHA 12/7   bare body  Ciao, Bravo, Grande, Si 20mph
01 098128 $5.00 adjuster A13 with nut M6-0.75
02 120074 $3.00 lock nut M5-0.75           special thread
03 113903 $6.00 cable pipe 2ar replica
04 120073 $3.00 lock nut M6-0.75
05 113906 $2.00 top screw M4-0.75 x 14 flat
06 113902 $12.0 carb top top-pull type, there’s no carb top gasket
07 113901 $10.0 spring throttle Ø11 x 26
08 135734 $15.0 throttle slide 21x26x3  has a ramp to release choke
09 124753 $3.00 rubber washer 2x7x1.5 slips into a pocket from the side
10 124598 N/A     slide rod Ø2 x 35          like Peugeot (28mm) but bigger
11 124597 N/A     rocker arm Ø5 hole
12 092403 N/A     step bolt Ø5 x 2 step, M4-0.75 x 10 shank
13 016320 $0.50 thin washer M5
14 014404 $0.50 lock washer M4
15 012012 N/A     nut M4-0.75              not a regular M4-0.70
16 124752 N/A     screw M4-0.75×10 sunk  can be a flat head
17 098130 $3.00 spring Ø5 x 7 x 12
18 098128 $6.00 cable adjuster M5-0.75
19 124596 N/A     carb top side-pull type #1 to 19 is “carb top” assy
21 133921 $6.00 choke lever Ciao            21 to 49 is “bottom” assy
22 353882 $15.0 choke lever Grande
23 140342 $17.0 choke lever Bravo     very long
24 113917 $10.0 inlet bolt M5-0.75 x 18  can not be normal M5-0.80
25 082920 $2.00 seal washer 5 x 8           can not be normal 5 x 10
26 113914 $7.00 banjo fuel inlet
27 113916 $6.00 fuel filter  Ø11 x 8
28 113915 $6.00 seal washer 11 x 16
29 114482 $17.0 intake sleeve 16 x 18 smaller than 20mm, regular SHA
29 222222 $2.00 rubber washer 12x18x2 not for 70’s Vespa moped
30 113926 $5.00 bolt M6-1.0 x 20             special small head
31 113927 $0.80 thin nut M6-1.0
32 113923 $4.00 spring for choke plate  torsion spring
33 113922 $4.00 pivot bolt choke            shoulder bolt
34 098135 $2.00 spring for idle screw
35 113919 $4.00 idle screw M4-0.70
36 164149 N/A     choke pull rod            Bravo P, Si
37 188772 N/A     choke pull rod            Ciao P
38 186413 N/A     coupling pipe (clip)  Si, Ciao P, Bravo P
39 212930 N/A     bracket                        Bravo P
40 188164 N/A     bracket                        Ciao P
41 164147 N/A     choke plate long flat    Si
42 188162 N/A     choke plate short bent Ciao P, Bravo P
43 120519 N/A     jet 39  20mph ’78-on Ciao, Bravo, Grande, Si, Ciao P
43 135233 N/A     jet 41  25mph ’80-83 Si, 30kph ’84-86 Bravo P
43 191125 $5.00 jet 42  25mph ’80-86 Ciao P
43 113912 none   jet 43 ’80-86 Si, ’68-77 Ciao, ’72-77 Bravo (all 30)
43 010101 $5.00 jet 44
43 130525 none   jet 45 ’78-83 Ciao (25, 30), Bravo (30)
43 010101 $5.00 jet 46
43 158780 $7.00 jet 49  30, 25mph ’78-85 Grande,
43 158780 $0.00 jet 49  30mph ’84-86 Ciao P, Bravo P, Si
43 010101 $5.00 jet 50

Vespa air filters L, 3-hole, R, 6-hole. Row 1 covered: L Kinetic, R Grande. Row 2 open: L, Ciao, R, Ciao P

Vespa air filters: L 3-hole, R 6-hole.
Row 1 covered: L Kinetic, R Grande
Row 2 open: L Ciao, R Ciao P

1. Ciao 3-hole, width 98mm
2. Ciao PX 6-hole, width 96mm
3. Kinetic 3-hole, width 90mm
Ciao ones are too wide to fit Kinetic.





















44 090506 $10.0 float needle L=17.0 photo
45 113910 $15.0 float all plastic says 2.5 grams 7420.1
46 113909 $2.00 gasket float bowl
47 085291 $2.00 hinge pin Ø2.0 x 16.5
48 113908 $12.0 float bowl metal
49 098134 $4.00 bowl screw M4-0.75 x 18
50 131009 $5.00 air filter screen
51 113055 $9.00 clamp air filter w/screw
53 113347 $25.0 air filter 3-hole open     68-80 Ciao,Bravo(20,25,27)
54 306922 $24.0 air filter 6-hole covered 78-86 Grande (20, 25, 30)
55 183423 $32.0 air filter 6-hole open     81-86 Ciao PX (30mph)
56 186886 N/A     air filter 3-hole open     80-86 Si, Ciao PX (20, 25)
57 000000 N/A     air filter 3-hole covered 95-99+ Kinetic TFR



















Franco Morini Identification 1954 to 1968

March 10, 2021







1954-56



Identification: The P48 has horizontal lines on the side covers. The P3 has no lines. The P48 has a large oil plug in the middle. The P3 has a small check plug just below the name plate.

1954-56 FBM P48 Pettiroso
47.7cc (38 x 42mm) 2-speed cable-shift with pedals
40km/h, ?? carburetor (9? mm)
case mounts: 2 rear and one top
piston 38.0 x 12-22.0-?? M16
rings 38.0 x 2.5 GN

1955-56 FBM P3
47.7cc (38 x 42mm) 3-speed cable-shift kick start
40km/h, Dellorto T4 9 S1 carburetor (9mm)
case mounts: 2 rear and 1 front,
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN

1954 FBM P48 Pettirosso

1955 FBM P48

1955 FBM P3

















 1957-59



First engines by Franco Morini in 1956-57 were mostly the same as 1954-56 Moto FBM. They have very rounded head fins. The differences are: 1) the 3M head has longer fins, 2) 3M has a motor mount, 2) the 3M case has no front mount.

First hourglass logo was on the these 1958 engine covers.

2-speed

1957-59? Morini 2M-48 (almost same as FBM P48)
47.7cc (38 x 42mm) 2-speed manual-clutch cable-shift with pedals
40km/h, Dellorto T4 9 S1 carburetor (9mm)
case mounts: 2 rear and 1 top
piston 38.0 x 12-22.0-??? M16
rings 38.0 x 2.5 GN

3-speed

1957-59? Morini 3M-48 (almost same as FBM P3)
47.7cc (38 x 42mm) 3-speed manual-clutch cable-shift kick-start
40km/h, Dellorto T4 9 S1 carburetor (9mm)
case mounts: 2 rear, and 1 head mount
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN


1958 Morini 48 Catalog (scaled) from www.motomanuali.i
Full scale version: 1958 2M-48 3M-48 Parts Catalog


2M and 3M cases and covers are different

1960-62? Morini 75
??cc (?? x 42mm) 3-speed foot shift
Dellorto ME16BS carburetor

1960 Morini 75



















 1960-61



2-speed

1960-62? Morini 2M/R
47.7cc (38 x 42mm) 2-speed manual-clutch cable-shift with pedals
1.3 hp, 40km/h, 5.8 cr, Dellorto T4 9 S1 carb (9 mm) 54 jet,
sprockets 14 x 27T

1960-62? Morini 2B/R
47.7cc (38 x 42mm) 2-speed manual-clutch cable-shift with pedals
case mounts: 2 rear and 1 top

1960-62? Morini F48
47.7cc (38 x 42mm) 2-speed manual-clutch with pedals
40km/h, Dellorto T4 9 S1 carburetor (9mm), jet 52


1960 Morini F48 two-speed

3-speed

1960-62? Morini 3M/R
47.7cc (38 x 42mm) 3-speed manual-clutch cable-shift kick-start
1.3 hp, 40km/h, 5.8 cr, Dellorto T4 9 S1 carb (9 mm) 54 jet,
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN, sprockets 13 x 30T

1960-62? Morini 3B/R
47.7cc (38 x 42mm) 3-speed manual-clutch cable-shift kick-start?
40km/h, Dellorto T4 9 S1 carburetor (9mm)
case mounts: 2 rear, and 1 head mount

1960-62? Morini 3M Export
47.7cc (38 x 42mm) 3-speed manual-clutch cable-shift kick-start
1.8 hp, 50km/h, 6.3 cr, Dellorto T4 12 S1 carb (12 mm) 54 jet,
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN, sprockets 13 x 28T


1960 Motori 48 Series Parts Catalog (incomplete)

1960 Morini 3M/R

1960 Morini 3M/R

1961? Morini 3M/V




















Morini 3M Series 1960’s









 1962-63



New 50cc bore and stroke: From 1962 to 1978 Franco Morini increased the cylinder bore from 38.0 to 39.0 mm, and decreased the stroke from 42.0 to 41.5 mm. This increased the displacement from 47.7 to 49.6 cc. First was the 3CV in 1962. Then the 3M and 4M series changed in 1969. Then the S5 series changed in 1978. By the 1980’s all 50cc Morini engines had a 39.0 bore.

2-speed

1962-64? Morini 2M/O Omologato (Homologated)
47.7cc (38 x 42mm) 2-speed manual-clutch cable-shift with pedals

3-speed

1962-64? Morini 3M
47.7cc (38 x 42mm) 3-speed manual-clutch cable-shift with pedals
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN

1962-64? Morini 3M/S Sport
47.7cc (38 x 42mm) 3-speed manual-clutch cable-shift with pedals
?? hp, ?? km/h, Dellorto UA16S, Dansi ASL11 magneto ∅110, ext spark
new head with larger fins

1962-64? Morini 3M/K
47.7cc (38 x 42mm) 3-speed manual-clutch cable-shift kick start
2.2? hp, 50 km/h, Dellorto SHA 14/12 carb (12mm)
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN

1962-64? Morini 3M/V
49.6cc (39.0 x 41.5) 3-speed manual-clutch cable-shift kick-start
2.2? hp, 50 km/h, Dellorto SHA 14/12 carb (12mm)
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN

1962-64? Morini 3CV
49.6cc (39.0 x 41.5) 3-speed manual-clutch cable-shift with pedals
2.2? hp, 50 km/h, Dellorto SHA 14/12 carb (12mm)
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN



1962 Motori 48 Parts Catalog (scaled) from www.motomanuali.it
Full scale version: 1962 Motori 48 Parts Catalog on motomanuali.it.


1963? Morini 3CV 3M/S 3M/SS Instruction Booklet (incomplete)







 1964-65



2M is retired: In 1964 the 2-speed 2M engine was discontinued in favor of the 3-speed 3M.

1-speed

1964-66? Morini F4
47.7cc (38 x 42mm) 1-speed automatic with pedals
1.3 hp, 40 km/h, 5.8 comp ratio, Dellorto T4 12 S1 carburetor
see Morini F4 Owners Manual at motomanuali.it .
new head with longer fins



1965-68? Morini F5
49.6cc (39.0 x 41.5) 1-speed auto. pedal-start, no pedals
2.2? hp, 50 km/h, Dellorto SHA 14/12 carb, Dansi MDL111 magneto

1965? Morini F5

1968? Morini F5

















3-speed

New horizontal lines: 1964-68 3M and 4M engines had rounded engine cases with horizontal lines across the middle of the side covers. Before 1964 only 2M engines had lines. This is useful in identification.

1964-66? Morini 3M Omologato
47.7cc (38 x 42mm) 3-speed manual-clutch cable-shift with pedals
1.4 hp, 40 km/h, Dellorto SHA 14/9 carb (9mm)
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN

1964-66? Morini 3M Export
47.7cc (38 x 42mm) 3-speed manual-clutch cable-shift with pedals
2.2? hp, 50 km/h, Dellorto SHA 14/12 carb (12mm)
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN

1964-65? Morini 3M/S
47.7cc (38 x 42mm) 3-speed manual-clutch cable-shift with pedals
?? hp, ?? km/h, Dellorto ME16-BS (16mm)

1964-65? Morini 3M/K
47.7cc (38 x 42mm) 3-speed manual-clutch cable-shift kick start
2.2? hp, 50 km/h, Dellorto SHA 14/12 carb (12mm)
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN

1964-65? Morini 3MV Ventilated (fan cooled)
49.6cc (39.0 x 41.5) 3-speed manual-clutch cable-shift with pedals
2.2? hp, 50 km/h, SHA 14/12 carb Dansi MSL111V2 or ASL123V
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN

1964-65? Morini 3CV  Ventilated (fan cooled)
49.6cc (39.0 x 41.5) 3-speed manual-clutch cable-shift kick-start
?? hp, ?? km/h, Dellorto ME16BS (16mm)
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN


1964 Morini 3M Parts Catalog (incomplete)

1964? 3M

1964? Morini 3M

1965 Morini 3CV

1965? Morini 3M/S
















1965 Morini 3MV Parts Catalog (early part#’s)







4-speed

1964-66? Morini 4MP
47.7cc (38.0 x 42.0) 4-speed manual-clutch foot-shift kick-start
Omologati 1.3 hp @4400, 40 km/h
Export xx  2.0 hp @6500, 60 km/h
Dansi magneto, Dellorto SHA 14/12 carb
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN




1964? Morini 4M Series Instruction Booklet
Full scale version see motofox.it .











 1966-68



1-speed

1966-69? Morini SA
47.7cc (38.0 x 42.0) 1-speed automatic with pedals
?? hp, ?? km/h, Dellorto SHA 14/12 carb,
Dansi MSL111 magneto
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027


1967? Morini SA Parts Catalog (late part#’s)



1966-70? Morini S5  1-speed automatic
47.7cc (38.0 x 42.0), 6.5 comp. ratio, pedal start
2.2hp 50kph or 1.4hp 40kph, SHA 14/12 or 14/9 carb
Dansi MDL111 magneto
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027

’66? Morini S5



3-speed

1966-72? Morini 3M
47.7cc (38.0 x 42.0) 3-speed manual-clutch cable-shift with pedals
2.2? hp, 50 km/h, Dellorto SHA 14/12 carb, Dansi MSL111 magneto
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN

1966-72? Morini 3M/K
47.7cc (38.0 x 42.0) 3-speed manual-clutch cable-shift kick-start
2.2? hp, 50 km/h, Dellorto SHA 14/12 carb, Dansi MSL111 magneto
piston 38.0 x 12-22.0-16.5 M3A14 23-0101 G0027
rings 38.0 x 2.5 GN

1966-72? Morini 3M/S
47.7cc (38.0 x 42.0) 3-speed manual-clutch cable-shift with pedals


1966 Morini 3M Series Parts Catalog (early part #’s, incomplete)


1967? Morini 3M, 3M/K Parts Catalog (late part #’s)

1966 Morini 3M

1966 Morini 3M/S



















1966-68? Morini 3MV  Ventilated (fan cooled)
49.6cc (39.0 x 41.5) 3-speed manual-clutch cable-shift with pedals
?? hp, ?? km/h, Dellorto ME16BS ?
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN

1966-68? Morini 3MV/K  Ventilated (fan cooled)
49.6cc (39.0 x 41.5) 3-speed manual-clutch cable-shift kick start
?? hp, ?? km/h, Dellorto ME16BS ?
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN

1966-68? Morini 3CV  Ventilated (fan cooled)
49.6cc (39.0 x 41.5) 3-speed manual-clutch cable-shift kick-start
?? hp, ?? km/h, Dellorto ME16BS ?
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN

1966-68? Morini 3CV/s  Ventilated (fan cooled)
49.6cc (39.0 x 41.5) 3-speed manual-clutch cable-shift kick-start
?? hp, ?? km/h, Dellorto UA19S carb
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN


1966 Morini 3MV Series Parts Catalog (incomplete)

1968 Morini 3CV

















4-speed

1966-68 Morini 4MP
49.9cc (39.0 x 41.8) 4-speed manual-clutch foot-shift kick-start
Omologati 1.3 hp @4400, 40 km/h, SHA 14/12 carb, jet 56
Export xx  2.0 hp @6500, 60 km/h, SHA 14/12 carb,  jet 58
Dansi MSL111 magneto
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN

1966-68 Morini 4MP/S Turbo
49.9cc (39.0 x 41.8) 4-speed manual-clutch foot-shift kick-start
?? hp @8500, ?? cr. Dellorto UA19S carb, jet 92
Dansi ASL111 magneto
piston 39.0 x 12-22.0-16.5? 4MPA14 23-0107 G0026A
rings 39.0 x 2L and 39.0 x 1.5 GN

1966-68 Morini 4MP/V
49.9cc (39.0 x 41.8) 4-speed manual-clutch foot-shift kick-start
Omologati 1.3 hp @4400, 40 km/h, SHA 14/12 carb, jet 56
Export xx  2.0 hp @6500, 60 km/h, SHA 14/12 carb,  jet 58
Dansi ASL123V magneto with fan
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN

1966-68 Morini 4MP/SV
49.9cc (39.0 x 41.8) 4-speed manual-clutch foot-shift kick-start
?? hp @7500, ?? cr. Dellorto ME16BS carb, jet 64
Dansi ASL123V magneto with fan
piston 39.0 x 12-22.0-16.5? 4MPA14 23-0107 G0026A
rings 39.0 x 2L and 39.0 x 1.5 GN


1966 Morini 4MP Series Parts Catalog (early part #’s)
Full scale catalog from cjoint.com via mondo50cc.forumfree.it.


1968? Morini 4MP/S Parts Catalog (late part #’s)
Full scale catalog from mondo50cc.forumfree.it.



1968-71? Morini 4MP
49.9cc (39.0 x 41.8) 4-speed manual-clutch foot-shift kick-start
Omologati 1.3 hp @4400, 40 km/h, SHA 14/12 carb, jet 56
Export xx  2.0 hp @6500, 60 km/h, SHA 14/12 carb,  jet 58
Dansi MSL111 magneto
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN

1968-71? Morini 4MP/S Turbo
49.9cc (39.0 x 41.8) 4-speed manual-clutch foot-shift kick-start
6 hp @8500, 9.0 cr. Dellorto UA19S carb, jet 92
Dansi ASL111 magneto
piston 39.0 x 12-22.0-16.5? 4MPA14 23-0107 G0026A
rings 39.0 x 2L and 39.0 x 1.5 GN

1968-71? Morini 4MP/V
49.9cc (39.0 x 41.8) 4-speed manual-clutch foot-shift kick-start
Omologati 1.3 hp @4400, 40 km/h, SHA 14/12 carb, jet 56
Export xx  2.0 hp @6500, 60 km/h, SHA 14/12 carb,  jet 58
Dansi ASL123V magneto with fan
piston 39.0 x 12-22.0-16.5 3CVA14 00-0000 G0027
rings 39.0 x 2.5 GN

1968-71? Morini 4MP/SV
49.9cc (38.0 x 41.8) 4-speed manual-clutch foot-shift kick-start
4 hp @7500, 8.5 cr. Dellorto ME16BS carb, jet 64
Dansi ASL123V magneto with fan
piston 39.0 x 12-22.0-16.5? 4MPA14 23-0107 G0026A
rings 39.0 x 2L and 39.0 x 1.5 GN









« Previous Entries
Next Entries »
