A18. 12x1 female spigot right


A18   01z2391037  $19    ↑res ←off  on↓ Italy-made by OMG
A18b 5322-A 000 none  ←res  on↓ off→ Italy-made Franconi
A18c Piag. 180581 $45    ↑res ←off  on↓ Italy-made by Paioli

Links to photos of examples:
1976 Flandria Bermuda Hampton (cover hole widened)
1977 Flandria Bermuda Hampton (no cover no petcock)
1978 Flandria Bermuda Pembroke
1978 Vespa Bravo original
1978 Vespa Bravo gas tank original
1978 Cimatti City Bike (when 10-12 adaptor is there)
1978 JC Penney Pinto (no petcock)
1979 Columbia 2220 (sheet frame) original
1979 Columbia 2220 (sheet frame) with spigot down
1979 Batavus Starflite with spigot right
1982 Batavus Mondial with spigot right
1980 Columbia Medallion (top tank) original
1981 Murray 8320 original
Tomos 233727 gas valve original
2007 Tomos Sprint with 233727
1980 Sachs Prima original
1969 Honda PC50

Columbia sheet frame: The sheet metal frame Columbia is different from a tube frame Columbia. It can have different marketing names. Original valve was spigot right, but down, back, or left also fit.

Tomos A55: All Tomos models with the A55 engine have a 12×1 spigot right gas valve #233727, above the left side of the engine. Earlier A35 models had a opposite valve on the opposite side.

Vespa Bravo: This screw-on valve is for Vespa Bravos with a metal tank. Some have a plastic gas tank, with a different gas valve than this. See clamp-on valves below.

Flandria Bermuda: Bermuda (made by Flandria) mopeds use this vertical 12×1 spigot right valve, but in the horizontal position. There is no reserve function. The owners manual says that either rear or forward is closed (off), and outward is open (on). The valve handle is protected behind the cover. There is a finger width long slot in the right cover, for one-finger access.

A17. 12x1 female spigot left

A17 12×1 spigot left
01z2361059    $15
←reserve  on↓ off→
made in Italy by OMG

A17c 12×1 sp. left
403300    $15
←res  on↓  off→
made in Taiwan

Links to photos of examples:

1978 Garelli VIP original
1978 Sachs Westlake with spigot left
1978 Cimatti Town Bike original
1979 Batavus Starflite with spigot left
1979 Sachs Balboa with spigot left
1979 Columbia 2250 (tube frame, Solo engine)
1979 Columbia 2260 (tube frame, Sachs engine)
1980 Sachs Seville original
1980 Sachs Prima original
1985 Tomos Bullet original
1994 Tomos Sprint original
1998 Tomos Sprint original
2000 Avanti Autopower original
2001 Avanti Kobra original
2001 Avanti Super Sport original

Columbia with tube frame:The original valve on a Columbia Commuter (tube frame) was a vertical mount valve, mounted in the sideways position. So the valve faces up, instead of sideways. That is not bad, but the poor handle gets kicked easily since it is right where you step through the frame at. The original valve had a reserve tube that curved upward, like on a Puch side mount. The replacement valve has a short straight reserve tube. Sideways installation disables the reserve feature. Optionally, a longer curved soft aluminum reserve tube is available. See below.

A17b. 12x1 female spigot left with extended round knob

A17b 12×1 spigot left
round knob
401602 $18
←reserve  on↓ off→
made in Taiwan by FS

Links to photos of examples:

2007 Tomos LX

This valve was made to replace Tomos 229.455, on 1994-2013 top tanks. Before 1994 was 10×1 male.

A16. 12x1 female spigot back with clear trap

A16 12×1 spigot back
clear sediment trap
01z2101024  $18
←reserve  on↓ off→
made in Italy by OMG

PA50 original

Links to photos of examples:

1978 Honda PA50 Hobbit tank
1978 Honda PA50 Hobbit original
1993 Hero Panther original
2000 Kinetic TFR-USA original
2002 Whizzer with the tank hole drilled bigger

This valve has a clear sediment trap. Anything heavier than gasoline, like water, dirt, rust settles at the bottom. The trap not only filters, but allows visual monitoring of the fuel for purity.

Whizzer The 2002 Whizzer tank takes a 12×1 thread gas valve. But the original Whizzer valve has no reserve tube or fuel filter. To have those, the 6.3mm hole can be drilled to 7.0mm. Here it is shown with a A16 “spigot back” type valve, but a A18 “spigot right” type would be better.

A15. 12x1 female spigot back

A15 12×1 spigot back
01B1451015   $20
←reserve  on↓ off→
OMG made in Italy

Links to photos of examples:

1977 Garelli Sport original made by BAP
1977 Moto Guzzi Chiu original (lies above engine covers)
1978 Garelli Rally Sport original
1978 JC Penney Pinto original
1978 Sears Free Spirit original
1979 Batavus Starflite original
1980 AMF Roadmaster 130 original
1980 AMF Roadmaster 130
1980 Garelli VIP original
1980 Garelli Super Sport original
1983 Garelli Basic original (lies below engine cover)
1984 Garelli Basic original, needs long reserve tube due to the tank extension
1984 Garelli Monza GT original
1990’s Hero Panther, Pacer, Gizmo original

A14. 12x1 female spigot down

A14 12×1 spig. down
01B1351048  $15
←reserve  on↓ off→
Italian made OMG

Links to photos of examples:

1977 Batavus VA original
1978 Kreidler MP-9 with spigot down
1978 Sears Free Spirit silver original
1978 Sears Free Spirit silver original
1978 Sears Free Spirit red original
1979 Columbia 2220 with spigot down
1980 Concord Freedom with spigot down
1988 Motomarina Sebring original
2000 Kinetic TFR-USA original

This valve fits many mopeds. It is sometimes called “universal”, but it is not truly universal.

A13. 12x1.25 male spigot down

A13 12×1.25 male spigot down 01B1331034 $13
←reserve  on↓ off→  made in Italy by OMG

A13b. 12x1.25 male spigot left

A13b 12×1.25 male spigot left with custom adapter  N/A use A13
left is original, right is replacement

1977 Speed Bird BP48

’77 Speed Bird BP48

1977 Speed Bird BP48

1977 Angel BP48-S  replacement petcock

1979 Angel BP48-S

Speedbird BP48 and Angel BP48-S, tube frame models made in Taiwan by TYM, use this valve. The 1.25 thread is more coarse than 1.0.

A13b is an A4 plus a custom made adapter, 10×1.00 female to 12×1.25 male thread.

A12. 12x1 male spigot down

A12 12×1 male spigot down 01z4011005   $16
←reserve  on↓ off→  made in Italy by OMG

Peugeot Vogue

Peugeot Vogue

This 12×1 valve is a male thread, right hand (clockwise is tighter). All other 12×1 valves are female thread and have a turnbuckle nut with both left and right hand thread. With the turnbuckle nut removed, the other 12×1 valves are male thread, left hand (clockwise is looser).

Because the whole valve must be screwed in to install it, the handle knob detaches with a clip.

This valve fits a Peugeot Vogue, perfectly.

A11. 10x1.25 male spigot right

A11 10×1.25 male right
634982 $18
adjustable height
made in China

This valve fits tanks with M10-1.25 female thread

None of the mopeds on this site have this thread. It may be for Chinese motorized bicycle gas tanks.

No reserve just OFF and ON.

Nut adjusts vertical height to fit closer or farther from tank.

Direction adjusts 360 degrees (like most others).

A10. 10x1 male spigot left with 26mm extender

A10 10×1 spigot left
26mm extender
2231010-b $29
←reserve on↓ off→

Links to photos of examples:

1992 Tomos Colibri original

At left is a used leaking original, not for sale, for a ’92 Tomos Colibri. At right is a new replacement, for sale. It is either an A4b 403200 (shown) or an A4 01z2351035 (red) valve, with a 1 inch extender.  It includes a 1 inch longer reserve tube and both outer seal rings.

A9. 10x1 male spigot down with 26mm extender

A9 10×1 spig. down
26mm extender
01z2231010-c $29
←res on↓ off→
Italy-made by OMG

This 10×1 spigot down valve has a 26mm extender that positions the valve lower, away from the bottom of the tank. The 26mm extender includes a longer reserve tube.

When an extender is added to a valve, the reserve tube needs to be longer. When the reserve tube is too short, there is little or no reserve. Here the original reserve tube has been replaced with a longer one, 60mm from the valve base instead of 35mm.

Any of the other 10×1 male valves can have a 15, 20, or 26mm extender added. Some already have long reserve tubes.
