Myrons Mopeds

A14. 12x1 female spigot down

A14 12×1 spig. down
01B1351048  $15
←reserve  on↓ off→
Italian made OMG

Links to photos of examples:

1977 Batavus VA original
1978 Kreidler MP-9 with spigot down
1978 Sears Free Spirit silver original
1978 Sears Free Spirit silver original
1978 Sears Free Spirit red original
1979 Columbia 2220 with spigot down
1980 Concord Freedom with spigot down
1988 Motomarina Sebring original
2000 Kinetic TFR-USA original

This valve fits many mopeds. It is sometimes called “universal”, but it is not truly universal.

A13. 12x1.25 male spigot down

A13 12×1.25 male spigot down 01B1331034 $13
←reserve  on↓ off→  made in Italy by OMG

A13b. 12x1.25 male spigot left

A13b 12×1.25 male spigot left with custom adapter  N/A use A13
left is original, right is replacement

1977 Speed Bird BP48

’77 Speed Bird BP48

1977 Speed Bird BP48

1977 Angel BP48-S  replacement petcock

1979 Angel BP48-S

Speedbird BP48 and Angel BP48-S, tube frame models made in Taiwan by TYM, use this valve. The 1.25 thread is more coarse than 1.0.

A13b is an A4 plus a custom made adapter, 10×1.00 female to 12×1.25 male thread.

A12. 12x1 male spigot down

A12 12×1 male spigot down 01z4011005   $16
←reserve  on↓ off→  made in Italy by OMG

Peugeot Vogue

Peugeot Vogue

This 12×1 valve is a male thread, right hand (clockwise is tighter). All other 12×1 valves are female thread and have a turnbuckle nut with both left and right hand thread. With the turnbuckle nut removed, the other 12×1 valves are male thread, left hand (clockwise is looser).

Because the whole valve must be screwed in to install it, the handle knob detaches with a clip.

This valve fits a Peugeot Vogue, perfectly.

A11. 10x1.25 male spigot right

A11 10×1.25 male right
634982 $18
adjustable height
made in China

This valve fits tanks with M10-1.25 female thread

None of the mopeds on this site have this thread. It may be for Chinese motorized bicycle gas tanks.

No reserve just OFF and ON.

Nut adjusts vertical height to fit closer or farther from tank.

Direction adjusts 360 degrees (like most others).

A10. 10x1 male spigot left with 26mm extender

A10 10×1 spigot left
26mm extender
2231010-b $29
←reserve on↓ off→

Links to photos of examples:

1992 Tomos Colibri original

At left is a used leaking original, not for sale, for a ’92 Tomos Colibri. At right is a new replacement, for sale. It is either an A4b 403200 (shown) or an A4 01z2351035 (red) valve, with a 1 inch extender.  It includes a 1 inch longer reserve tube and both outer seal rings.

A9. 10x1 male spigot down with 26mm extender

A9 10×1 spig. down
26mm extender
01z2231010-c $29
←res on↓ off→
Italy-made by OMG

This 10×1 spigot down valve has a 26mm extender that positions the valve lower, away from the bottom of the tank. The 26mm extender includes a longer reserve tube.

When an extender is added to a valve, the reserve tube needs to be longer. When the reserve tube is too short, there is little or no reserve. Here the original reserve tube has been replaced with a longer one, 60mm from the valve base instead of 35mm.

Any of the other 10×1 male valves can have a 15, 20, or 26mm extender added. Some already have long reserve tubes.

A8. 10x1 male spigot down with 20mm extender

A8 10×1 spigot down
20mm extender
01z2231010-b $29
←reserve on↓ off→
Italy-made by OMG

Links to photos of examples:

1978 Pacer Sport P78 original A8 (can use A2)
1979 Motron Classic with just the extender (can use A5)
1980 Motron Fairway no tank extender (can use A2)
1980 AMF Roadmaster 140 original A8
1983 AMF Roadmaster 140 replacement

A8 This valve is an A2 plus a C10.195 extender. The extender costs as much as the valve, so when replacing a 10mm valve that has an extender it is better to re-use the extender.

AMF with Minarelli: The 1980-83 AMF Roadmaster 140, 141 with Minarelli V1 mid-engine is another model that needs a short extender to position the valve knob to go through the hole in the body panel. This A8 replacement shown in the link fits, but the end of the handle must be ground off.

A8b. 10x1 male spigot left with 20mm extender

1978 Malaguti Pilot original A8b (can use A4)
1980 Pacer Super Sport original A8b (can use A4)

A8b This valve is an A4 plus a C10.195 extender. This configuration was on Malaguti Pilot and Baretta Magum. Can use just A4 without extender.

A8c. 10x1 male spigot right with 20mm extender

A8c 10×1 spigot right
with extender  $29
←res on↓ off→
Italy made by OMG

Links to photos of examples:

1980 Peugeot 102SP original A8c
1980 Peugeot 102SP original A8c

A8c This valve is an A5 plus a C10.195 extender. This configuration was on 1980 Peugeot 102 SP (US model) and others.

Peugeot 102: On 1980 Peugeot 102 there is a wall that prevents the valve from being screwed in, unless there is an extender piece between the valve and the tank. This model must have the extender present.

A7. 10x1 male spigot down with 15mm extender

A7 10×1 spigot down
short 15mm extender
222836 $23 on-off-res
Taiwan-made by F&S

Links to photos of examples:

1987 Tomos A3 Bullet TT
1993 Tomos A35 Bullet TT
1994 Tomos Sprint TT

This valve fits early 1987-93 Tomos top tanks with 10×1 internal threads. After 1993-94 Tomos top tanks have 12×1 external threads and take valve A17b.

The knob has to be removed in order to screw on because the tank wall is too close. Once installed the round knob goes through a one inch hole in the right plastic panel below the tank.

Here it is shown without the metal cup and rubber ring, but those things are included. The 15mm length extension includes the cup and rubber.

A6. 10x1 male spigot back medium shaft

A6 10×1 spigot back
medium shaft
01b1402283b  $15
←reserve  on↓ off→
Italy-made by OMG

NVT original 10×1 back,
long detachable shaft

Links to photos of examples:

1977 NVT Easy Rider
1978 Scorpion SC2
70’s Solex 8000 Tenor (Laura M54)
74-75 Solex Tenor 8000 (Laura M56)

Like the other 10×1 male valves, the whole valve must turn around and around, to screw on. But the long shaft would usually hit something. That would prevent the valve from screwing on. The original valves had a detachable shaft, held on by a clip. So the valve could be installed or removed without the shaft.

This replacement valve does not have an easily detachable shaft. But the shaft can be removed by loosening the shaft nut. To install the valve, remove the shaft, then screw on the valve, tighten only to a little more than “finger tight”, aim it to face outward or whatever direction is best, then replace the shaft.

A5. 10x1 male spigot right

A5 10×1 spigot right
1b15001017  $15
←res  on↓ off→
Italy made by OMG

Links to photos of examples:

1976 Itom Automatic
1978 Safari Super Extra
1978 Pacer Sport (original was A8)
1979-89 Di Blasi R7     #141 on left side
1989-97 Di Blasi R7TB #141 on left side
1996 Di Blasi R7 original

 Any top-tank model, with a 10 x 1 threaded hole on the left side (and nothing nearby) would use this A5 petcock.
